Installing the stainless steel
tubing in the unit
Make sure the stainless steel tube is
not kinked or damaged. Do not trim
stainless steel tube.
^
Remove the water connection cover
at the lower rear side of the coffee
machine.
^
Take the angled side of the stainless
steel tube and check whether the
sealing ring is in place. If necessary,
insert it.
^ Place the union nut of the stainless
steel tube onto the screw thread.
^ Make sure the fittings are tight.
Connection to the water
supply
Disconnect the machine from the
electrical supply before connecting
it to the water supply.
A faucet with a 3/4" connection thread
is required for the connection.
^
Check whether the sealing ring is in
place. If necessary, insert it.
^ Connect the stainless steel tube to
the shut-off valve.
You must only use the stainless steel
tube supplied. Old or used tubes
must never be connected to the
coffee machine.
^
Make sure the fittings are tight.
^
Slowly open the shut-off valve to the
water supply and check for leaks.
If necessary, check whether the
sealing ring and fittings are tight.
You can now continue with the
installation of the unit (see "Installation").
Plumbing
