To reassemble the lid:
^
First insert the gasket in the lid. Then
insert the milk intake pipe into the
gasket.
Make sure not to slide the beveled
end of the milk intake hose into the
gasket.
Step 2: Cleaning the air intake
hose and angle section in the
door
Do not use a needle or similar sharp
item. These can cause damage to
the parts.
^ Pull the main dispenser all the way
down.
^
Open the service cover on the back
of the door.
^
First detach the air intake hose a
from the opening c. Then pull off the
angled section b.
^ Pull both hoses out of the angled
section.
^ Clean the air intake hose a using the
cleaning brush supplied. "Blowing
through" can also shake loose
clogged residue.
^ Clean the opening for the air intake
hose c in the door.
^ Clean the angle section b under
running water. If necessary, replace it
with the supplied spare part.
^
Insert the brush into the milk hose d.
Move the brush back and forth until
all milk residue has been removed.
Cleaning clogged milk pipework
70
