Installation and Operation
Table Of Contents
- Contents
- IMPORTANT SAFETY INSTRUCTIONS 5
- Guide to the coffee system 10
- Controls and display elements 12
- Accessories 13
- First steps to use 14
- Operation 17
- Filling the water tank 18
- Filling the coffee bean container 19
- Turning the coffee machine on and off 20
- Adjusting the coffee dispensers to the cup height 21
- Preparing beverages 22
- Preparing espresso, coffee or lungo (large) coffee 22
- Preparing double portions 22
- Cancel preparation 23
- Preparing multiple cups of coffee, one directly after another (coffee pot) 23
- Preparing coffee beverages from ground coffee 23
- Beverages with milk 25
- Preparing hot water 26
- Preparing beverages from a profile 26
- After use 26
- Customizing your coffee 27
- Setting the serving size 30
- Settings 36
- Accessing the "Settings" menu 36
- Change and save settings 36
- Overview of possible settings 37
- Language 39
- Time of day 39
- Date 39
- Timer 39
- Eco mode 41
- Lighting 41
- Info (displaying information) 42
- Locking the coffee system ( System lock 0 ) 42
- Water hardness 42
- Display brightness 42
- Volume 42
- Activating and deactivating the plumbed water connection 42
- Factory default settings 43
- Showroom program ( demo mode ) 43
- Descaling 58
- Frequently asked questions 60
- Cleaning clogged milk pipework 69
- After sales service 72
- Installation instructions 73
- Caring for the environment 74
- Plumbing 75
- Lead free certificate 77
- Electrical connection 78
- Installation 79
- Adresses 87
Unsatisfactory result
Problem Possible cause and remedy
The consistency of
the milk froth is
unsatisfactory.
The milk temperature is too high. Good milk froth is
prepared with cold milk (< 55°F/13°C).
^
Check the milk temperature in the milk container.
The milk pipework or the air intake hose is clogged.
^
Follow the instructions in chapter "Cleaning clogged milk
pipework".
The grinding of the
coffee beans
sounds louder
than usual.
The coffee bean container has run empty during the
grinding process.
^ Fill the coffee bean container with fresh beans.
There might be pebbles mixed in with the coffee beans.
^ Turn the coffee machine off immediately. Contact Miele
Technical Service.
Espresso or coffee
flows into the cup
too quickly.
The grind level is too coarse.
^ Set the grinder control to a finer setting (see "Adjusting the
grinder setting").
Espresso or coffee
flows into the cup
too slowly.
The grind level is too fine.
^
Set the grinder control to a coarser setting (see "Adjusting
the grinder setting").
The coffee or
espresso is not hot
enough.
The cup has not been pre-heated.
The brewing temperature is set too low.
^
Set a higher brew temperature (see "Brewing
temperature").
The brew unit filters are blocked.
^
Remove the brew unit and clean it by hand (see "Brew
unit" ).
^
Degrease the brew unit (see "Brew unit").
Frequently asked questions
67
