Installation and Operation
Table Of Contents
- Contents
- IMPORTANT SAFETY INSTRUCTIONS 5
- Guide to the coffee system 10
- Controls and display elements 12
- Accessories 13
- First steps to use 14
- Operation 17
- Filling the water tank 18
- Filling the coffee bean container 19
- Turning the coffee machine on and off 20
- Adjusting the coffee dispensers to the cup height 21
- Preparing beverages 22
- Preparing espresso, coffee or lungo (large) coffee 22
- Preparing double portions 22
- Cancel preparation 23
- Preparing multiple cups of coffee, one directly after another (coffee pot) 23
- Preparing coffee beverages from ground coffee 23
- Beverages with milk 25
- Preparing hot water 26
- Preparing beverages from a profile 26
- After use 26
- Customizing your coffee 27
- Setting the serving size 30
- Settings 36
- Accessing the "Settings" menu 36
- Change and save settings 36
- Overview of possible settings 37
- Language 39
- Time of day 39
- Date 39
- Timer 39
- Eco mode 41
- Lighting 41
- Info (displaying information) 42
- Locking the coffee system ( System lock 0 ) 42
- Water hardness 42
- Display brightness 42
- Volume 42
- Activating and deactivating the plumbed water connection 42
- Factory default settings 43
- Showroom program ( demo mode ) 43
- Descaling 58
- Frequently asked questions 60
- Cleaning clogged milk pipework 69
- After sales service 72
- Installation instructions 73
- Caring for the environment 74
- Plumbing 75
- Lead free certificate 77
- Electrical connection 78
- Installation 79
- Adresses 87
Fault Possible cause and solution
Fault 73
or
"Check the brew
unit"
The brew unit cannot reset to the correct position or it is
clogged and the ground coffee cannot be processed.
^
Check if you can remove the brew unit (see "Cleaning and
care – Brew unit").
^
If you can remove the brew unit, clean it (see "Cleaning
and care – Brew unit").
^ Push the coffee ejector of the brew unit into the correct
position (see image).
^ Reinsert the waste unit and the water tank. Do not insert
the brew unit. Close the door and turn on the coffee
machine using the On/Off button K .
The brew unit motor will automatically move to the correct
position.
^
When the message "Insert the brew unit" is displayed, open
the door and reinsert all parts into the unit.
If you cannot remove the brew unit:
^
Turn off the coffee machine using the On/Off button K .
Wait about 2 minutes and then turn it on again.
Frequently asked questions
61
