Installation and Operation
Table Of Contents
- Contents
- IMPORTANT SAFETY INSTRUCTIONS 5
- Guide to the coffee system 10
- Controls and display elements 12
- Accessories 13
- First steps to use 14
- Operation 17
- Filling the water tank 18
- Filling the coffee bean container 19
- Turning the coffee machine on and off 20
- Adjusting the coffee dispensers to the cup height 21
- Preparing beverages 22
- Preparing espresso, coffee or lungo (large) coffee 22
- Preparing double portions 22
- Cancel preparation 23
- Preparing multiple cups of coffee, one directly after another (coffee pot) 23
- Preparing coffee beverages from ground coffee 23
- Beverages with milk 25
- Preparing hot water 26
- Preparing beverages from a profile 26
- After use 26
- Customizing your coffee 27
- Setting the serving size 30
- Settings 36
- Accessing the "Settings" menu 36
- Change and save settings 36
- Overview of possible settings 37
- Language 39
- Time of day 39
- Date 39
- Timer 39
- Eco mode 41
- Lighting 41
- Info (displaying information) 42
- Locking the coffee system ( System lock 0 ) 42
- Water hardness 42
- Display brightness 42
- Volume 42
- Activating and deactivating the plumbed water connection 42
- Factory default settings 43
- Showroom program ( demo mode ) 43
- Descaling 58
- Frequently asked questions 60
- Cleaning clogged milk pipework 69
- After sales service 72
- Installation instructions 73
- Caring for the environment 74
- Plumbing 75
- Lead free certificate 77
- Electrical connection 78
- Installation 79
- Adresses 87
Limescale builds up in the coffee
machine during use. The limescale
buildup in the machine will depend on
the hardness of your local water supply.
Limescale must be removed regularly.
The machine will guide you through the
descaling process. Various instructions
will appear on the display, e.g. you will
be prompted to empty the drip tray or
fill the water container.
Descaling is required and takes
approximately 20 minutes.
During the descaling program, water
containing descaling agent will run out
of the main dispenser and the hot water
spout. This is followed by an activation
period before a little more water with
descaling agent is dispensed, etc.
The coffee system will remind you on
the display when the descaling
program needs to be carried out. The
display will show "No. of uses until
appliance needs descaling: 50". The
remaining number of beverages that
can be made before descaling will
show in the display after each
beverage is made.
^
Tap the OK button to confirm this
message.
When the number of remaining
beverages is 0, the coffee system will
lock. The display will read, "Descale the
appliance".
You can turn the coffee machine off if
you do not want to run the descaling
program at this time. However, no more
beverages can be prepared until the
descaling program has been
completed.
Descaling following display
reminder
^
To immediately start the descaling
process, tap the OK button.
The descaling program cannot be
canceled once it has started. The
program must be completed through
to the end.
The descaling process is started and
various messages will appear in the
display.
^
Follow the instructions.
When the display shows "Fill water
container with lukewarm water and
descaling solution up to the F symbol
and insert", proceed as follows:
Preparing the descaling solution
The descaling tablets supplied have
been specially formulated for use with
this coffee machine. Additional
descaling tablets are available from the
Mieleusa.com website.
You will need two descaling tablets for
the descaling process.
Only use the Miele descaling
tablets. Other types of descaling
agents can damage the machine
and affect the taste.
Descaling
58
