Carefully pull the brew unit out of the
coffee machine.
If you cannot remove the brew unit or
can only do so with difficulty, the brew
unit is not in the correct position (see
"Frequently asked questions").
When the brew unit has been pulled
out, do not alter the position of the
brew unit handle.
This would displace the brew unit
and it would not fit back into the
coffee machine.
^ Clean the brew unit by hand while
running it under hot water.Donot
use soap.
^
Rub any coffee residue from the
filters. One filter is located inside the
funnel, the other to the left of the
funnel.
^
Dry the funnel to prevent ground
coffee sticking to it during the next
coffee preparation.
^
Clean the inside of the coffee
machine. Use your vacuum cleaner
to remove dry coffee grounds.
To replace the brew unit, repeat the
previous steps in the reverse order:
^
Push the brew unit back into the
coffee machine, making sure it is
straight.
^ Push the button on the bottom of the
brew unit handle a and turn the
handle to the right b.
^ Close the door.
Cleaning and care
55
