Installation and Operation
Table Of Contents
- Contents
- IMPORTANT SAFETY INSTRUCTIONS 5
- Guide to the coffee system 10
- Controls and display elements 12
- Accessories 13
- First steps to use 14
- Operation 17
- Filling the water tank 18
- Filling the coffee bean container 19
- Turning the coffee machine on and off 20
- Adjusting the coffee dispensers to the cup height 21
- Preparing beverages 22
- Preparing espresso, coffee or lungo (large) coffee 22
- Preparing double portions 22
- Cancel preparation 23
- Preparing multiple cups of coffee, one directly after another (coffee pot) 23
- Preparing coffee beverages from ground coffee 23
- Beverages with milk 25
- Preparing hot water 26
- Preparing beverages from a profile 26
- After use 26
- Customizing your coffee 27
- Setting the serving size 30
- Settings 36
- Accessing the "Settings" menu 36
- Change and save settings 36
- Overview of possible settings 37
- Language 39
- Time of day 39
- Date 39
- Timer 39
- Eco mode 41
- Lighting 41
- Info (displaying information) 42
- Locking the coffee system ( System lock 0 ) 42
- Water hardness 42
- Display brightness 42
- Volume 42
- Activating and deactivating the plumbed water connection 42
- Factory default settings 43
- Showroom program ( demo mode ) 43
- Descaling 58
- Frequently asked questions 60
- Cleaning clogged milk pipework 69
- After sales service 72
- Installation instructions 73
- Caring for the environment 74
- Plumbing 75
- Lead free certificate 77
- Electrical connection 78
- Installation 79
- Adresses 87
Interior and unit door
^
Clean the interior and the unit door
with warm water and liquid dish soap
once all removable parts have been
removed.
Tip: Use a vacuum cleaner to remove
dry ground coffee residue.
In the lower part of the inside door there
is a drip catcher.
^ Remove this cup and clean it in the
dishwasher or by hand using warm
water and liquid dish soap.
Remember to reinsert the drip
catcher.
Brew unit
Clean the brew unit by hand only
using hot water. Do not use soap.
The moving parts of the brew unit
are lubricated. Detergents will
damage the brew unit.
Clean the brew unit once a week.
Removing the brew unit and rinsing
it by hand
The brew unit can be removed for
cleaning. To do this:
^ Open the unit door.
^ Remove the water tank, the waste
unit, and the ground coffee chute lid.
^
Push on the bottom of the brew unit
handle a and turn the handle to the
left b.
^
Press the brew unit catch c
downward, and carefully pull the
brewing unit out.
Cleaning and care
54
