Drip tray cover
^
Remove the drip tray cover.
^
The drip tray cover can be cleaned in
the dishwasher or by hand using
warm water and liquid dish soap.
^
Dry the drip tray cover thoroughly.
^ Replace the cover onto the drip tray.
Make sure that the front of the cover
is flush with the drip tray.
Bean container
^
Pull the bean container out of the unit
and pull the lid toward the back and
off.
^
Clean the bean container and its lid
by hand using warm water and liquid
dish soap. Dry both components.
^
Slide the lid back on, then slide the
bean container back into the unit.
Main dispenser connector
A connecting piece between the brew
unit and the main dispenser is located
on the inside of the door.
^
Clean this connector on a regular
basis with a damp cloth, but take
care not to remove the lubricant from
the cap.
^
Once a month, lubricate the cap with
the supplied silicone grease.
Cleaning and care
53
