Installation and Operation
Table Of Contents
- Contents
- IMPORTANT SAFETY INSTRUCTIONS 5
- Guide to the coffee system 10
- Controls and display elements 12
- Accessories 13
- First steps to use 14
- Operation 17
- Filling the water tank 18
- Filling the coffee bean container 19
- Turning the coffee machine on and off 20
- Adjusting the coffee dispensers to the cup height 21
- Preparing beverages 22
- Preparing espresso, coffee or lungo (large) coffee 22
- Preparing double portions 22
- Cancel preparation 23
- Preparing multiple cups of coffee, one directly after another (coffee pot) 23
- Preparing coffee beverages from ground coffee 23
- Beverages with milk 25
- Preparing hot water 26
- Preparing beverages from a profile 26
- After use 26
- Customizing your coffee 27
- Setting the serving size 30
- Settings 36
- Accessing the "Settings" menu 36
- Change and save settings 36
- Overview of possible settings 37
- Language 39
- Time of day 39
- Date 39
- Timer 39
- Eco mode 41
- Lighting 41
- Info (displaying information) 42
- Locking the coffee system ( System lock 0 ) 42
- Water hardness 42
- Display brightness 42
- Volume 42
- Activating and deactivating the plumbed water connection 42
- Factory default settings 43
- Showroom program ( demo mode ) 43
- Descaling 58
- Frequently asked questions 60
- Cleaning clogged milk pipework 69
- After sales service 72
- Installation instructions 73
- Caring for the environment 74
- Plumbing 75
- Lead free certificate 77
- Electrical connection 78
- Installation 79
- Adresses 87
To activate and deactivate the timer
If the timer for "Turn on at" is activated,
the + symbol and the desired turn-on
time will appear on the display 23:59
hours before if the time display has
been set to "On" or "Overnight
shutdown".
If the system lock has been
activated, the timer function "Turn on
at" cannot be selected.
Select the timer function you want. The
selected timer function is marked as 9 .
^ Tap the arrow key X until "Accept" is
highlighted.
Tap the OK button.
Eco mode
The eco mode is a power-saving mode.
The steam system will only heat up
once a coffee beverage or steam for
hot milk and milk froth is requested.
If eco mode is turned off, milk froth and
hot milk as well as coffee and espresso
can be prepared consecutively. The
steam system remains heated up and
uses significantly more energy.
The coffee machine will indicate the
changed energy consumption.
Lighting
The following options are available:
–
Adjust the brightness of the lighting
while the machine is turned on.
–
Adjust the brightness of the lighting
while the machine is turned off.
–
Specify when the lighting should turn
off ("Turn off after").
Adjusting the brightness
First select:
–
Machine turned on
– Machine turned off
Use the arrow keys to adjust the
brightness.
To turn the lighting off:
^ Tap the arrow key X until the white
bars are no longer visible and
"Turned off" appears on the display.
Lighting: Setting the turn-off time
(Turn off after)
You can select for how long the coffee
machine should be illuminated after it
has been turned off.
In turned-on mode, the coffee machine
will remain illuminated for another 10
minutes after the last action. You
cannot change this time.
Tap the arrow keys to set the hours and
minutes.
Settings
41
