Installation and Operation
Table Of Contents
- Contents
- IMPORTANT SAFETY INSTRUCTIONS 5
- Guide to the coffee system 10
- Controls and display elements 12
- Accessories 13
- First steps to use 14
- Operation 17
- Filling the water tank 18
- Filling the coffee bean container 19
- Turning the coffee machine on and off 20
- Adjusting the coffee dispensers to the cup height 21
- Preparing beverages 22
- Preparing espresso, coffee or lungo (large) coffee 22
- Preparing double portions 22
- Cancel preparation 23
- Preparing multiple cups of coffee, one directly after another (coffee pot) 23
- Preparing coffee beverages from ground coffee 23
- Beverages with milk 25
- Preparing hot water 26
- Preparing beverages from a profile 26
- After use 26
- Customizing your coffee 27
- Setting the serving size 30
- Settings 36
- Accessing the "Settings" menu 36
- Change and save settings 36
- Overview of possible settings 37
- Language 39
- Time of day 39
- Date 39
- Timer 39
- Eco mode 41
- Lighting 41
- Info (displaying information) 42
- Locking the coffee system ( System lock 0 ) 42
- Water hardness 42
- Display brightness 42
- Volume 42
- Activating and deactivating the plumbed water connection 42
- Factory default settings 43
- Showroom program ( demo mode ) 43
- Descaling 58
- Frequently asked questions 60
- Cleaning clogged milk pipework 69
- After sales service 72
- Installation instructions 73
- Caring for the environment 74
- Plumbing 75
- Lead free certificate 77
- Electrical connection 78
- Installation 79
- Adresses 87
Select timer
The available options are:
–
Timer 1:
Turn on at, Turn off at, Turn off after
–
Timer 2:
Turn on at, Turn off at
Turn on at
Please note that the coffee machine
will not turn on at the required time if
you have activated the system lock.
Tap the arrow keys to set the hours and
minutes.
If the coffee machine has turned itself
on automatically three times using the
timer function "Turn on at" but no drinks
have been dispensed, the machine will
not turn itself on again automatically.
This prevents the coffee machine from
turning itself on unnecessarily, for
example while you are away on holiday.
The programmed times will, however,
remain in memory and will be
reactivated after manually turning the
machine on again.
Turn off at
Tap the arrow keys to set the hours and
minutes.
If you are away for a while, the stored
times will be reactivated after the next
time the machine is manually turned on
(see "Turn on at").
Turn off after
The timer function "Turn off after" is
only available with the Timer 1 option.
If none of the buttons has been pressed
or no beverage has been prepared, the
coffee machine will turn itself off after
30 minutes to save energy.
You can change this default setting
using the arrow keys and select a time
between 15 minutes and 9 hours.
Assign weekdays (Days of the week)
Select the day of the week you want.
The selected weekday is marked as 9 .
Once all desired weekdays are
checked:
^ Tap the arrow key X until "Accept" is
highlighted.
Tap the OK button.
Settings
40
