Installation and Operation
Table Of Contents
- Contents
- IMPORTANT SAFETY INSTRUCTIONS 5
- Guide to the coffee system 10
- Controls and display elements 12
- Accessories 13
- First steps to use 14
- Operation 17
- Filling the water tank 18
- Filling the coffee bean container 19
- Turning the coffee machine on and off 20
- Adjusting the coffee dispensers to the cup height 21
- Preparing beverages 22
- Preparing espresso, coffee or lungo (large) coffee 22
- Preparing double portions 22
- Cancel preparation 23
- Preparing multiple cups of coffee, one directly after another (coffee pot) 23
- Preparing coffee beverages from ground coffee 23
- Beverages with milk 25
- Preparing hot water 26
- Preparing beverages from a profile 26
- After use 26
- Customizing your coffee 27
- Setting the serving size 30
- Settings 36
- Accessing the "Settings" menu 36
- Change and save settings 36
- Overview of possible settings 37
- Language 39
- Time of day 39
- Date 39
- Timer 39
- Eco mode 41
- Lighting 41
- Info (displaying information) 42
- Locking the coffee system ( System lock 0 ) 42
- Water hardness 42
- Display brightness 42
- Volume 42
- Activating and deactivating the plumbed water connection 42
- Factory default settings 43
- Showroom program ( demo mode ) 43
- Descaling 58
- Frequently asked questions 60
- Cleaning clogged milk pipework 69
- After sales service 72
- Installation instructions 73
- Caring for the environment 74
- Plumbing 75
- Lead free certificate 77
- Electrical connection 78
- Installation 79
- Adresses 87
Filling ground coffee
Use the scoop supplied with the
machine to ensure the correct amount
of ground coffee is used.
Do not add more than one level
scoop of ground coffee to the coffee
chute. If too much ground coffee is
filled into the chute the brew unit
cannot process it.
The coffee machine will use all the
ground coffee that you have filled into
the chute for the next coffee
preparation.
^ Open the appliance door.
^
Pull out the cover of the ground
coffee chute. Open the lid of the
ground coffee chute.
^
Place a level scoop of ground coffee
into the chute.
^
Close the ground coffee chute and
slide the cover back into the
machine. Close the door.
The display shows the message "Use
ground coffee?"
Preparing coffee beverages from
ground coffee
If you want to prepare a coffee
beverage from ground coffee:
^
Tap the arrow buttons until "Yes" is
highlighted. Tap the OK button.
You can now select which coffee
beverage you want prepared from the
ground coffee.
^
Place a cup under the main
dispensers.
^ Tap the button for the desired
beverage.
The desired coffee beverage will be
prepared.
If you don't wish to prepare a beverage
from ground coffee:
^ Tap the arrow buttons until "No" is
highlighted. Tap the OK button.
The ground coffee will be directed into
the waste container.
If no button is pressed within
approx. 15 seconds, the ground
coffee is emptied into the waste
container.
Preparing beverages
24
