Installation and Operation
Table Of Contents
- Contents
- IMPORTANT SAFETY INSTRUCTIONS 5
- Guide to the coffee system 10
- Controls and display elements 12
- Accessories 13
- First steps to use 14
- Operation 17
- Filling the water tank 18
- Filling the coffee bean container 19
- Turning the coffee machine on and off 20
- Adjusting the coffee dispensers to the cup height 21
- Preparing beverages 22
- Preparing espresso, coffee or lungo (large) coffee 22
- Preparing double portions 22
- Cancel preparation 23
- Preparing multiple cups of coffee, one directly after another (coffee pot) 23
- Preparing coffee beverages from ground coffee 23
- Beverages with milk 25
- Preparing hot water 26
- Preparing beverages from a profile 26
- After use 26
- Customizing your coffee 27
- Setting the serving size 30
- Settings 36
- Accessing the "Settings" menu 36
- Change and save settings 36
- Overview of possible settings 37
- Language 39
- Time of day 39
- Date 39
- Timer 39
- Eco mode 41
- Lighting 41
- Info (displaying information) 42
- Locking the coffee system ( System lock 0 ) 42
- Water hardness 42
- Display brightness 42
- Volume 42
- Activating and deactivating the plumbed water connection 42
- Factory default settings 43
- Showroom program ( demo mode ) 43
- Descaling 58
- Frequently asked questions 60
- Cleaning clogged milk pipework 69
- After sales service 72
- Installation instructions 73
- Caring for the environment 74
- Plumbing 75
- Lead free certificate 77
- Electrical connection 78
- Installation 79
- Adresses 87
Preparing espresso, coffee or
lungo (large) coffee
^ Place a cup under the main spout.
^ Tap the touch key for the desired
beverage:
. Espresso
/ Coffee
x in "More programs": Lungo
coffee
The chosen coffee beverage will now
be dispensed.
To ensure that any residues from the
factory testing process are removed
from the brewing system, please
discard the first two cups of coffee
when using the machine for the first
time.
Preparing double portions
You can request two portions of
espresso or coffee at once in one cup
or in two separate cups simultaneously.
To fill two cups at the same time,
^ Place a cup under each coffee
dispenser.
^ Tap °.
The ° symbol is illuminated.
^ Tap the touch key for the desired
beverage.
Two portions of the desired beverage
will be dispensed from the coffee
dispensers.
Tip: If you do not tap any beverage
keys for a while, the "Double portion" °
selection will be reset.
Preparing beverages
22
