Granite and marble worktops
The screws are not required for
granite or marble worktops.
^
Position and secure the spring
clamps a and spacer bars b using
strong, double-sided adhesive tape
c.
^
Apply silcone to the side edges and
the lower edges of the spring clamps
a and spacer bars b.
^
Then fill gap e between the spacer
bars and the worktop with silicone
from the tube supplied.
Fixing the spring clamps and spacer bars
