To service Throttle (continued)...
2. Lift up controller cover enough to expose wiring. Label and disconnect all wiring, including ground
3. Completely remove controller cover and set aside until reinstallation.
l Perform desired repair or equipment replacement.
l Reconnect wires and reinstall. Check for pinched wires
To service Steering Assembly.. .
l Switch off power to game machine and unplug AC line cord.
l Unlock and open rear cabinet door.
l Label and disconnect wiring, including ground strap, for steering assembly.
l Remove controller assembly
1. Remove tamper-resistant screws used to fasten controller
co’ver
to the housing and set aslde
2. Lift up controller cover enough to expose wiring.
3. Label and disconnect all wiring, including ground
4. Completely remove controller cover and set aside until reinstallation.
5. Locate and remove center hub. Remove screws from hub, lift hub from shaft, then set aside until
reinstallation.
6.Locate and remove jam nut and lock washer used to fasten controller housing to motor shaft.
7. Grab each controller grip and
lift
up and away from dashboard.
If
controller housing sticks. perform
bulleted steps listed below, otherwise adwnce to step 8.
l Replace the hub removed in step 5. Fasten in place with the screws provided.
l Locate hex-head bolt. This bolt is secured with a retention clip inside of the controller assembly
l Insert bolt in hub and tighten down until the controller housing begins to lift up and can be removed
completely.
l Be sure to return bolt to retention clip for future use.
8. Set aside controller housing with matching hardware until reinstallation.
9. Locate and remove Phillips head screws used to fasten the anti-pinch plate around motor shaft.
10. Remove anti-pinch plate and set aside with hardware until reinstallation.
l Remove dash pod:
1. Locate and remove tamper-resistant screws used to fasten pod to cabinet
2. Gently slide dash pod off of and away from cabinet.
3. Place pod in a safe place along with hardware to prevent breakage or loss
l Remove hex nuts used to fasten dash plate to cabinet.
l Pull plate forward to expose motor. Lift out Qeering assembly. NOTE: Use caution when removing motor
due to its weight.
l Perform desired repair or equipment replacement
-
