CHAPTER 3 SERVICE
To service Start and Attack Buttons...
l Switch off power to game machine and unplug AC line cord
l Remove controller assembly
I Remove tamper-resistant screws used to fasten controller cover to housing and set aside.
2. Lift up controller cover enough to expose wiring. Label and disconnect all wiring, including ground.
3. Completely remove controller cover.
l Perform desired repair or equipment replacement.
GENERAL DASH SERVICE
73 service Throttle.. .
Refer to Controller Service illustration.
l Switch off power to game machine and unplug AC line cord.
l Open rear cabinet door
l Label and disconnect all dash wiring, including ground strap.
l Remove controller assembly
1. Remove tamper-resistant screws used to fasten controller cover to housing and set aside
c
