CHAPTER 3 SERVICE
A
!
WARNING
Fluorescent tubes implode on impact when dropped. Use care in handling.
To service the Fluorescent Light Assembly...
Refer to Marquee Service illustration.
.
Switch off power to game machine and unplug the AC line cord.
.
Remove screws used to fasten the clear plastic overlay and mar’quee artwork to marquee.
.
Remove both the marquee overlay and artwork and set aside in a safe place to prevent damage.
.
Reach up Inside the opening in cabinet and disconnect the power cable from fluorescent light assembly.
.
Loosen, but do not remove the screws fastening assembly to cabinet.
.
Slide assembly slightly forward to disengage the keyholes. Lift out the assembly.
l Perform desired repair or equipment replacement.
MAROUEE ILLUSTRATION
ARCTIC THUNDER
5
