Specifications

CHAPTER 2 DIAGNOSTICS
1 Main Menu
I’
Diagnostic Menu, continued
Lamp Test
LAMP TEST
I
--/
To detect intermittent or faulty incandescent bulbs use the Volume Up or Volume Down buxon to select
LAMP TEST at the Diagnostic Menu. This test ensures that the incandescent bulbs critrcal to game opera-
tion function properly.
LAMP TEST -/
Use the Volume Up or Volume Down button to select desired Lamp Test and press the Test button. During
the test observe the Lamp(s) turn ON according to the option selected.
To return to the submenu, select Return and press the Test button; to return to the Main Menu scroll to
Back To Previous Menu and press the Test button.
~ Main Menu
! Diagnostic Menu, continued
!I
12pzaker Test
SPEAKER TEST
To verify the proper functionahty of the speaker assemblies use the Volume Up or Volume Down button to
select Speaker Test at the Dlagnostx Menu, then press the Test button.
I
SPEAKER TEST
I
RIGHT CHANNEL
LEFT CHANNEL
I KHZ SOUND
1 OOHZ SOUND
PLAY TUNE
RETURN
RIGHT CHANNEL. Tests the functionality of the speaker located on the right-hand side of ihe game cabi-
net by emitting an audible voicing of the word “right.”
LEFT CHANNEL. Tests the functionality of the speaker located on the left-hand side of the game cabinet
by emitting an audible voictng of the word “left.”
The 1 KHz and 1OOHz Sound tests are audible tones emitted from both speakers on the game cabinet
Play Tune test option emits audible music from the game using both speakers on the game cabinet.
18 MIDWAY AMUSEMENT GAMES, LLC
