E-Panels Explained

Breakers to fit on din rails
150VDC 13mm wide: 1,2,3,4,56,7,8,910,12,15,20,30,40,50,63 amps $13.00 list (example MNEPV15)
150VDC 63 amp (MNDC-GFP) $69.00 list
120VAC 13mm wide: 10,15, 20 amps UL489 branch circuit rated $15.00 list (example MNEAC15)
120VAC 13mm wide: 30,40, 50. 60 amps UL1077 supplementary protection $15.00 list (MNEAC50)
277VAC three phase breakers 39mm wide: 30 & 50 amp (MNEAC30-3P) and (MNEAC50-3P) $54.00 list
Internally used white short face 120VAC UL1077 15, 30 and 50 amp $15.00 list (MNEAC15 QZD)
Internally used white short face 2 pole 120/240VAC UL1077 30, 50 and 60 amp $30.00 list (MNEAC50 QZD2)
After building the first prototype E-Panel, we took it to Hawaii
where two professional installers and a distributor tore the design
apart. It was back to the drawing board after that trip. The
E-Panel has undergone a hundred changes over the last couple
of years thanks to suggestions from users and installers.
Ms. Morales. Just one of thousands of satisfied customers.
The money she saved by using the MidNite E-Panel was
Enough to buy another PV panel! This installation was done
by Positive Energy. Santa Fe, New Mexico.
Yes, there are two guys standing on the door of an E-
Panel with the door open and inverter installed.
This was actually a UL required test of the hinged
door.
Another Positive Energy installation
