User Guide

group group
matrix direct
aux out aux out
insert
G2 G1
2
1
2
1
in 1
1
insert
Each group buss can be connected to external equipment by means of one single
balanced male XLR socket (0dBu nominal level).
In addition to this, each group can be inserted into by means of a single
unbalanced quarter-inch TRS jack conventionally wired (0dBu nominal level).
Group Insert
Group Output
XLR Sockets
12 3
TRS Insert Jacks
TR S
- Screen - Signal Hot - Signal Cold
- Signal Send - Signal Return - Screen
Verona Group OutputsVerona Group Outputs
Operators Manual - Page 21
Rear Panel
Front Panel
Group Aux C/O - The group auxiliary
changeover switch is described on the
previous page. When enabled, auxiliary
signals are routed into the group output
controls and hence group should be
mentally changed to ‘aux’.
Group to Mtx - The group to mtx switch
routes the group signal to the matrix send
pots (discussed later in this section).
Mono
Pan
Mute
Solo
Fader
- When depressed, the signal will be
sent to the main mono buss via the master
sis switch.
- The pan control allows the channel
signal to be positioned in a stereo field when
routed to the stereo buss. The pan control
allows continuous adjustment of the image
from hard left, to hard right with a centre
detent and obeys a constant power law (i.e.
-3dB at the centre so that the output
remains at unity).
- The mute switch mutes the group
signal at all points after the insert return
(and hence any matrix sends).
- The solo switch sends the group
signal to the AFL stereo and PFL mono
busses.
- The fader allows continuous
adjustment of the group output level from
off (-inf) to +10dB.
Pre-Fade (Group to Mtx)
Stereo
- When
depressed, the signal sent to the matrix
send pots is sourced pre-fader and hence
the level will be proportional to the matrix
send pot only. This may be desirable if
using the matrix for recording or
monitoring (e.g. stage side fills).
- When depressed, the signal will
be sent to the main stereo buss via the pan
and master sis switch.
Master SIS - The master SIS switch will
enable the spacial imaging system
whereby the channel pan control operates
in a different way. When panned hard left,
signal is routed to the stereo left output as
normal, similarly when panned hard right,
the signal is routed to the stereo right
output as normal. However, when panned
centre, the signal is routed ONLY to the
mono output creating a LCR (left-centre-
right) system instead of the normal LR
(left-right) system.
aux
aux
c/o
pre
group
pan
group
fade
pre
mono
stereo
to mtx
c
lr
group 1
group 1
master
sis
10
10
5
5
0
20
15
30
40
SOLO
MUTE
aux
mtx
-24
pan
group
fade
pre
mono
stereo
to mtx
c
lr
+10
group 1
0
group 1
aux 1
aux
aux
c/o
pre
group
master
sis
10
10
5
5
0
20
15
30
40
SOLO
SOLO
MUTE
MUTE
aux aux
mtx
+21 +21
+18 +18
+15 +15
+12 +12
+9 +9
+6 +6
+3 +3
00
-3 -3
-6 -6
-9 -9
-12 -12
-15 -15
-18 -18
-21 -21
-24 -24
group meters
direct
mono
