cases where power consumption must be kept to a minimum, such as in
solar-powered installations.
Optional Arguments:
MODE=<mode>—Set mode as follows:
NONE: Normal
SLEEP: Sleep enabled. In this mode, the radio draws less than 20 mA
at 12 volts. It can be brought back online (ready to send data) within
75 milliseconds. Wake-up is accomplished by asserting the DTR
line on the
COM2 port, or by the appearance of payload data at the
active COM port.
SHUTDOWN: Shutdown enabled. Radio draws less than 1 mA @ 12
volts. This mode requires a longer wakeup time—almost as long as
if the radio were de-powered.
WAKE=<wake>—This selects a control option to activate(enter) or deacti-
vate(exit) sleep or shutdown modes.
DTR: Wake under DTR signal control
DATA: Wake up on data
PERIOD: Wake up periodically
DTRSENSE=<dtrsense>—DTR sense setting.
LOW: DTR Active LOW
HIGH: DTR Active HIGH
PERIOD=<period>—Wake-up period in seconds when SLEEP WAKE is
set to PERIOD. Acceptable value range is 5–86400
HANGTIME=<hangtime>—Minimum wake time in seconds before
returning to low power mode. Acceptable value range is 5–600
STATS
[ALL, RADIO, COM1, COM2, ETH, RESET]
This command displays radio statistics. If <device>
(
RADIO,COM1,COM2,ETH) is omitted, all statistics are displayed.
Optional Arguments:
ALL: Displays all statistics
RADIO: Displays radio packet statistics
COM1: Displays COM1 packet statistics
COM2:Displays COM2 packet statistics
ETH: Displays Ethernet packet statistics
RESET: Resets packet statistics for the indicated interface
