FORMAT=<format>—Sets / displays data characters, parity, and stop bits
setting of the COM port. Valid data parameters are:
7N1—7 char bits, no parity, 1 stop bit
7N2—7 char bits, no parity, 2 stop bits
7O1—7 char bits, odd parity, 1 stop bit
7O2— 7 char bits, odd parity, 2 stop bits
7E1—7 char bits, even parity, 1 stop bit
7E2—7 char bits, even parity, 2 stop bits
8N1—8 char bits, no parity, 1 stop bit (Default)
8N2—8 char bits, no parity, 2 stop bits
8O1—8 char bits, odd parity, 1 stop bit
8O2—8 char bits, odd parity, 2 stop bits
8E1—8 char bits, even parity, 1 stop bit
8E2—8 char bits, even parity, 2 stop bits
NOTE: Entry of data formats other than those listed above may cause
undesired operation.
BUFFER=<buffer>—Sets / displays maximum buffer size of the
COM port. Acceptable value range is 1–1500.
DELAYCHARS=<delaychars>—Sets / displays minimum inter-packet gap
for the COM port. Acceptable value range is 1–256
COM2
[MODE=<mode>, BAUD=<baud>, FORMAT=<format>, BUFFER=<buffer>, DELAY-
CHARS=<delaychars>]
This command Sets / displays the configuration of the COM2 port.
Optional Arguments:
MODE=<mode>—Sets / displays mode of the COM2 port. COM2 MODE
cannot be set to DATA unless the device has been authorized for serial
payload data.
DISABLED—COM2 data mode disabled
DATA—COM2 in transparent data mode
BAUD=<baud>—Sets / displays baud rate setting as1200, 2400, 4800,
9600, 19200, 38400, 57600, 115200 or 230400 bps.
Sets / displays data characters, parity, and stop bits setting of the COM
port. Valid data parameters are:
7N1—7 char bits, no parity, 1 stop bit
7N2—7 char bits, no parity, 2 stop bits
7O1—7 char bits, odd parity, 1 stop bit
7O2— 7 char bits, odd parity, 2 stop bits
7E1—7 char bits, even parity, 1 stop bit
