Specifications

MDS 05-4055A01, Rev. A MDS entraNET 900 System Guide 129
8.2 TECHNICAL SPECIFICATIONS
GENERAL
Temperature Range: –40° C to +70° C (–40° F to 158° F)
Humidity: 95% at +40° C (104° F); non-condensing
Primary Power: 6–30 Vdc (13.8 Vdc Nominal)
Supply Current (typical): 11 Watts Maximum @ 1 Watt RF Output
Transmit: AP: 800 mA @ 13.8 Vdc Remote: 600 mA
Receive: AP: 300 mA @ 13.8 Vdc Remote:150
Sleep (Remote): <20 mA @ 12 Vdc
Shutdown: <1 mA @ 12 Vdc
MTBF: 35 Years (Telcordia Method 1, Case 3)
Size (Excluding mtg. hardware): 1.5" x 6" x 4" (H x W x D)
3.8 x 15.2 x 10.2 cm
Weight: 0.9 kg / 2 lb (AP)
0.43 kg/0.95 lb (Remote)
Case: Cast Aluminum
Boot Time: AP: ≈ 30 seconds
Remote: ≈ 1 seconds
Time Required to Connect
with Access Point: <1 second typical
APPROVALS/HOMOLOGATION
• FCC Part 15.247
• Industry Canada RSS-210 and RSS-139
• UL/CSA Class 1, Div. 2; Groups A, B, C and D
hazardous locations
• Contact MDS for information on availability and
governmental approvals in other countries
EMBEDDED MANAGEMENT SYSTEM
Access Point: • HTTP (Embedded Web server)
• Text-based menu on COM1 serial port
• Telnet
5 Receive Data (RXD) Out
6 Transmit Data (TXD) In
7 Clear-to-Send (CTS) Out
8 Request-to-Send (RTS) In
Table 8-2. COM2 Port, EIA-232 Interface (Continued)
Pin Functions COM2 Port
(DCE)
