5.1.4 Point-to-Multipoint Serial-to-Serial Application
Example
The operation and data flow for this mode is very similar to a
Point-to-Point serial-to-serial application, except that it uses multicast
addressing. The primary difference is that data presented at the Access
Point’s
COM port will be packetized and sent to all of the Remotes. Upon
receiving the packet all of the Remotes strip the data out of the packet
and send it out their
COM port. Likewise, data presented at any of the
Remotes’
COM ports is packetized, sent to the Access Point, stripped,
and sent out the Access Point’s
COM port.
Invisible place holder
Figure 5-4. Point-to-Multipoint Serial-to-Serial Diagram
Seamless Mode Disabled
Buffer Size 256 Bytes
Inter-Packet Delay 4
Remote Unit (COM2) Mode Data
Baud 19200
Format 8N1
Buffer 256
DelayChars 4
Table 5-4. Point-to-Point Serial-to-Serial Configuration
