User manual

FCC Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful interference
(2) this device must accept any interference received including interference
that may cause undesired operations. This applies to all product options.
FCC Radio Frequency Interference Statement
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
» Reorient or relocate the receiving antenna.
» Increase the separation between the equipment and receiver.
» Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
» Consult the dealer or an experienced radio/TV technician for help. To comply with FCC
RF exposure compliance requirements, a separation distance of at least 20 cm must be
maintained between the antenna of this device and all persons. This transmitter
must not be collocated or operating in conjunction with any other antenna or transmitter.
Caution: Changes or modifications to this equipment not expressly approved by manufacturer
could void the user’s authority to operate this equipment.
Canadian Compliance Statement
Complies with the Canadian ICES-003 Class B specifications.
Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada.
IEC and CDRH Statements of Compliance
The SHOWWX+ HDMI complies with IEC 60825-1, 2007-03.
The device also complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant
to Laser Notice No. 50 dated June 24, 2007.
CE Statement
This product complies with the requirements of the Low Voltage Directive 2006/95/EC
and the EMC Directive 2004/108/EC and carries the CE mark accordingly.
This device meets the following standards:
EN60950-1:2006 – Safety of Information Technology Equipment
EN60825-1:2007 – Safety of Laser Products
EN55024: 1998 +A1:2001+A2:2003 – Immunity
EN55022: 2006 – Radiated & Conducted Emissions
Laser Specifications
The SHOWWX+™ HDMI Laser Pico Projector is a CLASS 2 LASER PRODUCT as defined
in IEC 60825-1, 2007-03. MicroVision has designed the SHOWWX+ HDMI to be safe
for general use as a mobile projector.
IEC and CDRH Statements of Compliance
The SHOWWX+ HDMI complies with IEC 60825-1, 2007-03. The device also complies with
21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50
dated June 24, 2007.
The following safety labels are affixed at the factory.
THESE LABELS CONTAIN IMPORTANT SAFETY INFORMATION. DO NOT REMOVE THEM.
Safety Labels Regulatory Statements
6 7
Located inside the SHOWWX+ HDMI.
Do not attempt to disassemble
the SHOWWX+ HDMI.
Bottom View
Laser
Color
Red Green Blue
AlGalnP
laser diode
Frequency doubled
IR laser diode
GaN
laser diode
120 mW 72 mW 50 mW
632 nm 526 nm 440 nm650 nm 537 nm 460 nm
Laser
Type
Max CW
Output
Wave-
length
