9. Guarantee
This instrument is covered by a 3 year guarantee from the date of purchase. The guarantee is valid only
on presentation of the guarantee card completed by the dealer confirming date of purchase or the receipt.
Batteries, cuff and wearing parts are not included. Opening or altering the instrument invalidates the
guarantee. The guarantee does not cover damage caused by improper handling, discharged batteries,
accidents or non-compliance with the operating instructions.
Name and company address of the responsible dealer:
10. Technical Specifications
This device complies with the requirements of the Medical Device Directive 93/42/EEC.
Technical alterations reserved.
11. www.microlife.com
Detailed user information about our products as well as services can be found at www.microlife.com.
Weight: 503 g (with batteries)
Size: 118 (W) x 177 (L) x 77 (H) mm
Storage temperature: -20 - +55 °C; 15 - 95 % relative maximum humidity
Operation temperature: 10 - 40 °C; 15 - 95 % relative maximum humidity
Display: LCD-Display (Liquid Crystal Display)
Measuring method: oscillometric
Pressure sensor: capacitive
Measuring range:
SYS/DIA:
Pulse:
20 to 280 mmHg
40 to 200 beats per minute
Cuff pressure display range: 0–299 mmHg
Memory: Automatically stores the last 99 measurements
Measuring resolution: 1 mmHg
Accuracy: Pressure within ± 3 mmHg
Pulse ± 5 % of the reading
Power source: DC 6 V / 600 mA
a) 4 dry cells (batteries) UM-3, size AA, 1.5 V
b) mains adaptor 6V DC 600 mA (optional)
Cuffs: Medium (AC-1-M) for arm circumference 22–32 cm or
Large (AC-1-L) for arm circumference 32–42 cm (optional)
Reference to standards: EN 1060-1 /-3 /-4; IEC 60601-1; IEC 60601-1-2 (EMC)
