User manual

24
9.6 Stand-alone setting
This menu offers options for stand-alone mode as a selection of the playing program,programming and modifying
current programs.
- Music trigger
The CYCLOPS 150 enables the sound control of the running programs via the built-in microphone.Use the [
] or [ ] buttons to select "On" if you wish this feature or "Off" if you don’t wish this feature and press [ ] to
confirm or [ ] to cancel and return to the menu.
-Presetting playback
This function allows you to select the the program which will be played in the stand-alone mode after switching
the fixture On.Use the [ ] or [ ] buttons to select desired program ("tESt"- bilt-in program) or "OFF" if you don't
want trigger any program after switching the fixture On and press [ ] to confirm or [ ] to cancel and return to
the menu.Selected program will be played continuously in a loop as long as it appears on the display.
This option should be set "OFF" for all slaves in the master/slave chain by reason of the right program starts.
For example: You have selected program "PrG.3" in this menu and:
this fixture is set as a single fixture (master/slave or controller operating)- the fixture will run its program "PrG.3".
this fixture is set as a master in a data chain- the fixture will run its program "PrG.3".
this fixture is set as a slave in a data chain- the fixture will run its program according to the master(if the master
runs its own program "PrG.1", the slave will run its own program "PrG.1"also).
Note:If the fixture operates in the controller mode ( DMX controller is connected) and any program from this menu
is selected ,in this case the fixture will not respond to the DMX controller after switching On and will play selected
program.
- Playing program
This function allows you to run a bilt-in program "tESt" and the 3 freely-programmable programs
"PrG.1,PrG.2,PrG.3" .Press [ ] or [ ] buttons to select the desired program and press [ ] to run the program
which will be played continuously in a loop.
If you want to pause the runnnig program in the required position, press the [ ]-button(messages"PAUS"/"
program No."blink ).To continue the program running,press the [ ]-button again.
Note:If the fixture operates in the controller mode ( DMX controller is connected) and any program from this
function is selected in this case the fixture will not respond to the DMX controller and will play selected program.
You can't play programs on the slave fixtures from their control panels if the master fixture is switched On and
connected to the slaves (playing is forced by the master).
