User manual

22
- Display -intensity
With this function you can adjust the display intensity from 20% to 100% . Use the [ ] or [ ]
buttons to select the level of the display intensity and press [ ] to confirm or [ ] to cancel
and return to the menu.
- Display-reverse
With this function, you can rotate the display by 180°. Use the [ ] or [ ] buttons to select "normal
display" or "display turned by 180°" and press [ ] to confirm or [ ] to cancel and return to the
menu.
- Display-On
This function allows you to keep the display on or to turn off automatically 2 minutes after last
pressing any button on the control panel. Use the [ ] or [ ] buttons to select "On" if you wish to
keep the display on or "Off" if you wish to turn off automatically 2 minutes after last pressing any
button on the control panel and press [ ] to confirm or [ ] to cancel and return to the menu.
- Blackout during movement correction
The function executes the blackout during the head movement correction (the moving head has lost its right pan/
tilt-position for a short moment). Use the [ ] and [ ] buttons to select "On" if you want to execute the blackout
or "Off" if you don’t and press [ ] to confirm or [ ] to cancel and return to the menu.
- PAN/TILT-feedback
This function allows to return the mowing head to the required pan/tilt position after changing the position by
external force (e.g.by stroke). Use the [ ] and [ ] buttons to select "On" if you wish to enable this function
or "Off" if you wish not to return the mowing head to the required position and press [ ] to confirm or [ ] to
cancel and return to the menu.
Note: If the feedback was switched off ,the pan/tilt-position is changed by an external force and the feedback is
switched on again,the moving head might not to be synchronized with the DMX signal.You have to make a reset
in order to synchronize the moving head with the DMX signal.
- Microphone -sensitivity
With this function you can adjust the microphone sensitivity from 1(maximum) to 20(minimum) . Use the [ ] or
[ ] buttons to select the level of the microphone sensitivity and press [ ] to confirm the chosen level or [
] to cancel and return to the menu.
Example:
underexited right level overexited
(upper segment blinks by the bass rhythm)
- Default settings
Press [ ] to reset all fixture personalities (not the adjusting functions) to the default values. On the display will
appear "rSt" meaning that the fixture makes the reset. See the table of personality setting and their default
positions.
