Fixation via the Omega holders
1. Screw each clamp (1) to the included Omega holders (4) with M12 bolt and nut through the hole in the holder.
2. Insert both quick-lock fasteners (3) into the holes of the base and tighten fully clockwise.Install the second
clamp.
3. Fasten the safety-rope (2) through the two apertures on the bottom of the base and over the trussing system.
1-Clamp
2-Safety-rope
3-Quick-lock fastener
4-Omega holder
4.5 Connection to the mains
Connect the fixture to the mains with the enclosed power-plug.
The earth has to be connected!
The occupation of the connection-cables is as follows:
Cable Pin International
Brown Live L
Light blue Neutral N
Yellow/Green Earth
