User's Manual

RU00-M04 RFID Spitfire Module Specifications
PAGE: 11
11- RU00-M04-X001-01
DATE: 10-25-2016
Pin
Number
Pin Name Type Description
1,2,3 VDC Power Power Supply
4 GND Ground Ground
5 USB_nSENSE Input
Active low pulse for USB enumeration
process. The low pulse need be more than
1ms.
6 USB_D+ I/O USB Data Signal Plus
7 USB_D- I/O USB Data Signal Minus
8 GND Ground Ground
9 UART1_TX Output UART Console Transmit Data
10 UART1_RX Input UART Console Receive Data
11 GND Ground Ground
12 ENABLE Input Active High Enable Device
13 WAKEUP Input Active High Wake up Device
14 GND Ground Ground
15 GPIO1 I/O General Purpose Input/Output
16 GPIO2 I/O General Purpose Input/Output
17 GPIO3 I/O General Purpose Input/Output
18 GPIO4 I/O General Purpose Input/Output
19 STATUS Output Status Indication
20 HEALTH Output Status Indication
Table 3: Pin Configurations of FPC connector
