RU00-M04 RFID Spitfire Module Specifications
PAGE: 10
11- RU00-M04-X001-01
DATE: 10-25-2016
5 Pin Configurations and Descriptions
The module is controlled via 20-pin FPC I/O connector. The pin configurations are shown in Figure 2 and
Table 3.
Figure 1: I/O Configurations
