NOTE: APPROVAL ON THIS PAGE SIGNIFIES THE ENTIRE DOCUMENT APPROVED. RU00-M04 RFID Spitfire Module Specifications A1 ECO- REV ECO NO. DATE DARWING NO.: 11- RU00-M04-X001-01 PAGE NO.
RU00-M04 RFID Spitfire Module Specifications 11- RU00-M04-X001-01 PAGE: 2 DATE: 10-25-2016 REVISION HISTORY DARWING NO.
PAGE: 3 RU00-M04 RFID Spitfire Module Specifications 11- RU00-M04-X001-01 DATE: 10-25-2016 RU00-M04-X001 / X011 Spitfire Module Datasheet Version 1.0.0 MTI Group Proprietary Information Any unauthorized use, duplication, reproduction, reverse engineering, decompilation, or disclosure of this document may be considered as infringement of MTI Group’s intellectual property rights, the infringer may be accused and liable applicable legal penalties. Copyright, Microelectronics Technology Inc..
RU00-M04 RFID Spitfire Module Specifications 11- RU00-M04-X001-01 PAGE: 4 DATE: 10-25-2016 Table of Contents 1 Introduction ................................................................................................................................ 5 2 Regulatory Statement................................................................................................................... 6 Federal Communication Commission Interference Statement .....................................................
PAGE: 5 RU00-M04 RFID Spitfire Module Specifications 11- RU00-M04-X001-01 DATE: 10-25-2016 1 Introduction The RU00-M04 is a FPC I/O connector, USB/UART interface that comprises a completely in integrated solution for EPC Gen 2 / ISO18000-63 (formerly 18000-6C) application. This document provides instructions to the end-user to ensure optimal performance in their OEM hardware. Model Number RU00-M04-X001 RU00-M04-X011 Supported Regions Operating Frequency US 902.75MHz~927.25MHz EU 865.7MHz~867.
PAGE: 6 RU00-M04 RFID Spitfire Module Specifications 11- RU00-M04-X001-01 DATE: 10-25-2016 2 Regulatory Statement Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (if EUT is portable device, please delete this item) (2) this device must accept any interference received, including interference that may cause undesired operation.
PAGE: 7 RU00-M04 RFID Spitfire Module Specifications DATE: 10-25-2016 11- RU00-M04-X001-01 This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna.
PAGE: 8 RU00-M04 RFID Spitfire Module Specifications 11- RU00-M04-X001-01 DATE: 10-25-2016 3 Specifications Item Description Specifications 1 Air Interface Protocol EPCglobal UHF Class 1 Gen2 / ISO 18000-63 (formerly 18000-6C) Supports dense reader mode (DRM) 2 3 Tx Output Power RF Connectors Range: +10 to +31.5 dBm UF.L*4 4 Dimensions Spitfire Module + Back Plate : 75 mm by 44 mm by 9 mm 5 I/O Connector FPC 20Pin 6 Rx Sensitivity -74dBm.
PAGE: 9 RU00-M04 RFID Spitfire Module Specifications 11- RU00-M04-X001-01 DATE: 10-25-2016 4 Set up HOST can control the ru00-m04 module through the USB or UART on the test board. The RU00-M04 can be easily powered by DC 5V. Set up refer to below figure.
RU00-M04 RFID Spitfire Module Specifications 11- RU00-M04-X001-01 PAGE: 10 DATE: 10-25-2016 5 Pin Configurations and Descriptions The module is controlled via 20-pin FPC I/O connector. The pin configurations are shown in Figure 2 and Table 3.
PAGE: 11 RU00-M04 RFID Spitfire Module Specifications DATE: 10-25-2016 11- RU00-M04-X001-01 Pin Number 1,2,3 4 Pin Name VDC GND Type Power Ground Description 5 USB_nSENSE Input 6 7 8 9 10 11 12 13 14 15 16 17 USB_D+ USB_DGND UART1_TX UART1_RX GND ENABLE WAKEUP GND GPIO1 GPIO2 GPIO3 I/O I/O Ground Output Input Ground Input Input Ground I/O I/O I/O Power Supply Ground Active low pulse for USB enumeration process. The low pulse need be more than 1ms.
RU00-M04 RFID Spitfire Module Specifications 11- RU00-M04-X001-01 6 Mechanical Information Mechanical Outline (Draft) Spitfire Module + Back Plate：75 x 44 x 9mm Figure 2: Package Mechanical Outline PAGE: 12 DATE: 10-25-2016
RU00-M04 RFID Spitfire Module Specifications 11- RU00-M04-X001-01 PAGE: 13 DATE: 10-25-2016 7 Interfacing to the RU00-M04 Power and Ground All circuits on the RU00-M04 are powered from inputs at pin 1, 2, 3. The RU00-M04 operates with any supply voltage between 3.3 and 5.25V. Because the individual supplies within the part are regulated on the RU00-M04, a large amount of supply filtering is not required.
RU00-M04 RFID Spitfire Module Specifications 11- RU00-M04-X001-01 PAGE: 14 DATE: 10-25-2016 Enable Pin 12 of the RU00-M04 comprises the ENABLE signal. The RU00-M04 is held in reset if the signal is held low. The ENABLE signal is bidirectional and is pulled down to 3.3V by ~10kΩ resistance internal to the RU00-M04. Any external connection to this pin must maintain a low impedance (<<10kΩ) other than when an external reset signal is applied.
