PIC18F2525/2620/4525/4620
TABLE 9-3: PORTB I/O SUMMARY
Pin Function
TRIS
Setting
I/O
I/O
Type
Description
RB0/INT0/FLT0/
AN12
RB0 0 O DIG LATB<0> data output; not affected by analog input.
1 I TTL PORTB<0> data input; weak pull-up when RBPU
bit is cleared.
Disabled when analog input enabled.
(1)
INT0 1 I ST External interrupt 0 input.
FLT0 1 I ST Enhanced PWM Fault input (ECCP1 module); enabled in software.
AN12 1 I ANA A/D input channel 12.
(1)
RB1/INT1/AN10 RB1 0 O DIG LATB<1> data output; not affected by analog input.
1 I TTL PORTB<1> data input; weak pull-up when RBPU
bit is cleared.
Disabled when analog input enabled.
(1)
INT1 1 I ST External interrupt 1 input.
AN10 1 I ANA A/D input channel 10.
(1)
RB2/INT2/AN8 RB2 0 O DIG LATB<2> data output; not affected by analog input.
1 I TTL PORTB<2> data input; weak pull-up when RBPU
bit is cleared.
Disabled when analog input enabled.
(1)
INT2 1 I ST External interrupt 2 input.
AN8 1 I ANA A/D input channel 8.
(1)
RB3/AN9/CCP2 RB3 0 O DIG LATB<3> data output; not affected by analog input.
1 I TTL PORTB<3> data input; weak pull-up when RBPU
bit is cleared.
Disabled when analog input enabled.
(1)
AN9 1 I ANA A/D input channel 9.
(1)
CCP2
(2)
0 O DIG CCP2 compare and PWM output.
1 I ST CCP2 capture input.
RB4/KBI0/AN11 RB4 0 O DIG LATB<4> data output; not affected by analog input.
1 I TTL PORTB<4> data input; weak pull-up when RBPU
bit is cleared.
Disabled when analog input enabled.
(1)
KBI0 1 I TTL Interrupt on pin change.
AN11 1 I ANA A/D input channel 11.
(1)
RB5/KBI1/PGM RB5 0 O DIG LATB<5> data output.
1 I TTL PORTB<5> data input; weak pull-up when RBPU
bit is cleared.
KBI1 1 I TTL Interrupt on pin change.
PGM x I ST Single-Supply Programming mode entry (ICSP™). Enabled by LVP
Configuration bit; all other pin functions disabled.
RB6/KBI2/PGC RB6 0 O DIG LATB<6> data output.
1 I TTL PORTB<6> data input; weak pull-up when RBPU
bit is cleared.
KBI2 1 I TTL Interrupt on pin change.
PGC x I ST Serial execution (ICSP™) clock input for ICSP and ICD operation.
(3)
RB7/KBI3/PGD RB7 0 O DIG LATB<7> data output.
1 I TTL PORTB<7> data input; weak pull-up when RBPU
bit is cleared.
KBI3 1 I TTL Interrupt on pin change.
PGD x O DIG Serial execution data output for ICSP and ICD operation.
(3)
x I ST Serial execution data input for ICSP and ICD operation.
(3)
Legend: DIG = Digital level output; TTL = TTL input buffer; ST = Schmitt Trigger input buffer; ANA = Analog level input/output;
x = Don’t care (TRIS bit does not affect port direction or is overridden for this option).
Note 1: Configuration on POR is determined by the PBADEN Configuration bit. Pins are configured as analog inputs by default
when PBADEN is set and digital inputs when PBADEN is cleared.
2: Alternate assignment for CCP2 when the CCP2MX Configuration bit is ‘0’. Default assignment is RC1.
3: All other pin functions are disabled when ICSP or ICD is enabled.
