PIC18F2525/2620/4525/4620
26.0 ELECTRICAL CHARACTERISTICS
Absolute Maximum Ratings
(†)
Ambient temperature under bias.............................................................................................................-40°C to +125°C
Storage temperature .............................................................................................................................. -65°C to +150°C
Voltage on any pin with respect to V
SS (except VDD and MCLR) ................................................... -0.3V to (VDD + 0.3V)
Voltage on V
DD with respect to VSS ......................................................................................................... -0.3V to +7.5V
Voltage on MCLR
with respect to VSS (Note 2)......................................................................................... 0V to +13.25V
Total power dissipation (Note 1) ...............................................................................................................................1.0W
Maximum current out of V
SS pin ...........................................................................................................................300 mA
Maximum current into V
DD pin ..............................................................................................................................250 mA
Input clamp current, I
IK (VI < 0 or VI > VDD)......................................................................................................................±20 mA
Output clamp current, I
OK (VO < 0 or VO > VDD) .............................................................................................................. ±20 mA
Maximum output current sunk by any I/O pin..........................................................................................................25 mA
Maximum output current sourced by any I/O pin ....................................................................................................25 mA
Maximum current sunk by all ports .......................................................................................................................200 mA
Maximum current sourced by all ports ..................................................................................................................200 mA
Note 1: Power dissipation is calculated as follows:
Pdis = V
DD x {IDD IOH} + {(VDDVOH) x IOH} + (VOL x IOL)
2: Voltage spikes below V
SS at the MCLR/VPP/RE3 pin, inducing currents greater than 80 mA, may cause
latch-up. Thus, a series resistor of 50-100Ω should be used when applying a “low” level to the MCLR
/VPP/
RE3 pin, rather than pulling this pin directly to V
SS.
NOTICE: Stresses above those listed under “Absolute Maximum Ratings” may cause permanent damage to the
device. This is a stress rating only and functional operation of the device at those or any other conditions above those
indicated in the operation listings of this specification is not implied. Exposure to maximum rating conditions for
extended periods may affect device reliability.
