PIC18F2480/2580/4480/4580
DS39637D-page 90 © 2009 Microchip Technology Inc.
B4D2
(8)
B4D27 B4D26 B4D25 B4D24 B4D23 B4D22 B4D21 B4D20 xxxx xxxx 63, 305
B4D1
(8)
B4D17 B4D16 B4D15 B4D14 B4D13 B4D12 B4D11 B4D10 xxxx xxxx 63, 305
B4D0
(8)
B4D07 B4D06 B4D05 B4D04 B4D03 B4D02 B4D01 B4D00 xxxx xxxx 62, 305
B4DLC
(8)
Receive mode
— RXRTR RB1 RB0 DLC3 DLC2 DLC1 DLC0 -xxx xxxx 63, 307
B4DLC
(8)
Transmit mode
—TXRTR— — DLC3 DLC2 DLC1 DLC0 -x-- xxxx 63, 307
B4EIDL
(8)
EID7 EID6 EID5 EID4 EID3 EID2 EID1 EID0 xxxx xxxx 63, 305
B4EIDH
(8)
EID15 EID14 EID13 EID12 EID11 EID10 EID9 EID8 xxxx xxxx 63, 304
B4SIDL
(8)
Receive mode
SID2 SID1 SID0 SRR EXID —EID17EID16xxxx x-xx 63, 303
B4SIDL
(8)
Transmit mode
SID2 SID1 SID0 —EXIDE —EID17EID16xxx- x-xx 63, 303
B4SIDH
(8)
SID10 SID9 SID8 SID7 SID6 SID5 SID4 SID3 xxxx xxxx 63, 302
B4CON
(8)
Receive mode
RXFUL RXM1 RXRTRRO FILHIT4 FILHIT3 FILHIT2 FILHIT1 FILHIT0 0000 0000 63, 301
B4CON
(8)
Transmit mode
TXBIF TXABT TXLARB TXERR TXREQ RTREN TXPRI1 TXPRI0 0000 0000 63, 301
B3D7
(8)
B3D77 B3D76 B3D75 B3D74 B3D73 B3D72 B3D71 B3D70 xxxx xxxx 63, 305
B3D6
(8)
B3D67 B3D66 B3D65 B3D64 B3D63 B3D62 B3D61 B3D60 xxxx xxxx 63, 305
B3D5
(8)
B3D57 B3D56 B3D55 B3D54 B3D53 B3D52 B3D51 B3D50 xxxx xxxx 63, 305
B3D4
(8)
B3D47 B3D46 B3D45 B3D44 B3D43 B3D42 B3D41 B3D40 xxxx xxxx 63, 305
B3D3
(8)
B3D37 B3D36 B3D35 B3D34 B3D33 B3D32 B3D31 B3D30 xxxx xxxx 63, 305
B3D2
(8)
B3D27 B3D26 B3D25 B3D24 B3D23 B3D22 B3D21 B3D20 xxxx xxxx 63, 305
B3D1
(8)
B3D17 B3D16 B3D15 B3D14 B3D13 B3D12 B3D11 B3D10 xxxx xxxx 63, 305
B3D0
(8)
B3D07 B3D06 B3D05 B3D04 B3D03 B3D02 B3D01 B3D00 xxxx xxxx 63, 305
B3DLC
(8)
Receive mode
— RXRTR RB1 RB0 DLC3 DLC2 DLC1 DLC0 -xxx xxxx 63, 307
B3DLC
(8)
Transmit mode
—TXRTR— — DLC3 DLC2 DLC1 DLC0 -x-- xxxx 63, 307
B3EIDL
(8)
EID7 EID6 EID5 EID4 EID3 EID2 EID1 EID0 xxxx xxxx 63, 305
B3EIDH
(8)
EID15 EID14 EID13 EID12 EID11 EID10 EID9 EID8 xxxx xxxx 63, 304
B3SIDL
(8)
Receive mode
SID2 SID1 SID0 SRR EXID —EID17EID16xxxx x-xx 63, 303
B3SIDL
(8)
Transmit mode
SID2 SID1 SID0 —EXIDE —EID17EID16xxx- x-xx 63, 303
B3SIDH
(8)
SID10 SID9 SID8 SID7 SID6 SID5 SID4 SID3 xxxx xxxx 63, 302
B3CON
(8)
Receive mode
RXFUL RXM1 RXRTRRO FILHIT4 FILHIT3 FILHIT2 FILHIT1 FILHIT0 0000 0000 63, 301
B3CON
(8)
Transmit mode
TXBIF TXABT TXLARB TXERR TXREQ RTREN TXPRI1 TXPRI0 0000 0000 63, 301
B2D7
(8)
B2D77 B2D76 B2D75 B2D74 B2D73 B2D72 B2D71 B2D70 xxxx xxxx 63, 305
B2D6
(8)
B2D67 B2D66 B2D65 B2D64 B2D63 B2D62 B2D61 B2D60 xxxx xxxx 63, 305
B2D5
(8)
B2D57 B2D56 B2D55 B2D54 B2D53 B2D52 B2D51 B2D50 xxxx xxxx 63, 305
TABLE 6-2: REGISTER FILE SUMMARY (PIC18F2480/2580/4480/4580) (CONTINUED)
File Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Value on
POR, BOR
Details on
Page:
Legend: x = unknown, u = unchanged, - = unimplemented, q = value depends on condition
Note 1: Bit 21 of the PC is only available in Test mode and Serial Programming modes.
2: The SBOREN bit is only available when CONFIG2L<1:0> = 01; otherwise, it is disabled and reads as ‘0’. See Section 5.4 “Brown-out Reset (BOR)”.
3: These registers and/or bits are not implemented on PIC18F2X80 devices and are read as ‘0’. Reset values are shown for PIC18F4X80 devices;
individual unimplemented bits should be interpreted as ‘—’.
4: The PLLEN bit is only available in specific oscillator configuration; otherwise, it is disabled and reads as ‘0’. See Section 3.6.4 “PLL in INTOSC
Modes”.
5: The RE3 bit is only available when Master Clear Reset is disabled (CONFIG3H<7> = 0); otherwise, RE3 reads as ‘0’. This bit is read-only.
6: RA6/RA7 and their associated latch and direction bits are individually configured as port pins based on various primary oscillator modes. When
disabled, these bits read as ‘0’.
7: CAN bits have multiple functions depending on the selected mode of the CAN module.
8: This register reads all ‘0’s until the ECAN™ technology is set up in Mode 1 or Mode 2.
9: These registers are available on PIC18F4X80 devices only.
