20.2 Selecting and Configuring
Automatic Acquisition Time
The ADCON2 register allows the user to select an
acquisition time that occurs each time the GO/DONE
bit is set.
When the GO/DONE
bit is set, sampling is stopped and
a conversion begins. The user is responsible for ensur-
ing the required acquisition time has passed between
selecting the desired input channel and setting the
GO/DONE
bit. This occurs when the ACQT<2:0> bits
(ADCON2<5:3>) remain in their Reset state (‘000’) and
is compatible with devices that do not offer
programmable acquisition times.
If desired, the ACQT bits can be set to select a
programmable acquisition time for the A/D module.
When the GO/DONE
bit is set, the A/D module
continues to sample the input for the selected acquisition
time, then automatically begins a conversion. Since the
acquisition time is programmed, there may be no need
to wait for an acquisition time between selecting a
channel and setting the GO/DONE
bit.
In either case, when the conversion is completed, the
GO/DONE
bit is cleared, the ADIF flag is set and the
A/D begins sampling the currently selected channel
again. If an acquisition time is programmed, there is
nothing to indicate if the acquisition time has ended or
if the conversion has begun.
20.3 Selecting the A/D Conversion
Clock
The A/D conversion time per bit is defined as TAD. The
A/D conversion requires 11 T
AD per 10-bit conversion.
The source of the A/D conversion clock is
software-selectable. There are seven possible options
for T
AD:
•2 T
OSC
•4 TOSC
•8 TOSC
•16 TOSC
•32 TOSC
•64 TOSC
• Internal RC Oscillator
For correct A/D conversions, the A/D conversion clock
(T
AD) must be as short as possible, but greater than the
minimum T
AD (approximately 2 μs, see parameter 130
for more information).
Table 20-1 shows the resultant TAD times derived from
the device operating frequencies and the A/D clock
source selected.
TABLE 20-1: TAD vs. DEVICE OPERATING FREQUENCIES
AD Clock Source (TAD) Maximum Device Frequency
Operation ADCS2:ADCS0 PIC18F2X80/4X80 PIC18LF2X80/4X80
(4)
2 T
OSC 000 2.86 MHz 1.43 kHz
4 TOSC 100 5.71 MHz 2.86 MHz
8 TOSC 001 11.43 MHz 5.72 MHz
16 T
OSC 101 22.86 MHz 11.43 MHz
32 TOSC 010 40.0 MHz 22.86 MHz
64 T
OSC 110 40.0 MHz 22.86 MHz
RC
(3)
x11 1.00 MHz
(1)
1.00 MHz
(2)
Note 1: The RC source has a typical TAD time of 1.2 ms.
2: The RC source has a typical TAD time of 2.5 ms.
3: For device frequencies above 1 MHz, the device must be in Sleep for the entire conversion or the A/D
accuracy may be out of specification.
4: Low-power (PIC18LFXXXX) devices only.
