PIC18F47J13 FAMILY
2. Module: Reset
Register 20-1 and Register 20-5 incorrectly define the
SSPxSTAT Reset state as ‘1111 1111’. The correct
Reset state of the SSPxSTAT is ‘0000 0000’.
3. Module: Electrical Characteristics
Changes, shown in bold, have been made to the D060,
D061 and D063 rows in Section 30.4 DC Characteris-
tics: PIC18F47J13 Family (Industrial). The updated
table is shown below:
30.4 DC Characteristics: PIC18F47J13 Family (Industrial)
DC Characteristics
Standard Operating Conditions (unless otherwise stated)
Operating temperature -40°C <
TA < +85°C for Industrial
Param
No.
Characteristic Typ Max Units Temp. Conditions
Input Leakage Current (I
IL)
(1,2)
D060 I/O Ports ±5 ±200 nA ±25ºC VSS  VPIN  VDD,
Pin at high-impedance
±15 ±500 nA ±85ºC
D061 MCLR
±5 ±200 nA ±25ºC VSS  VPIN  VDD
±15 ±500 nA ±85ºC
D063 OSC1 ±5 ±200 nA ±25ºC V
SS  VPIN  VDD
±15 ±500 nA ±85ºC
Note 1: The leakage current on the MCLR
pin is strongly dependent on the applied voltage level. The specified
levels represent normal operating conditions. Higher leakage current may be measured at different input
voltages.
2: Negative current is defined as current sourced by the pin.
