© 2006 Microchip Technology Inc. DS41159E-page 207
PIC18FXX8
REGISTER 19-5: TXBnSIDH: TRANSMIT BUFFER n STANDARD IDENTIFIER,
HIGH BYTE REGISTERS
REGISTER 19-6: TXBnSIDL: TRANSMIT BUFFER n STANDARD IDENTIFIER,
LOW BYTE REGISTERS
REGISTER 19-7: TXBnEIDH: TRANSMIT BUFFER n EXTENDED IDENTIFIER,
HIGH BYTE REGISTERS
R/W-x R/W-x R/W-x R/W-x R/W-x R/W-x R/W-x R/W-x
SID10 SID9 SID8 SID7 SID6 SID5 SID4 SID3
bit 7 bit 0
bit 7-0 SID10:SID3: Standard Identifier bits if EXIDE = 0 (TXBnSID Register) or
Extended Identifier bits EID28:EID21 if EXIDE = 1
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
R/W-x R/W-x R/W-x R/W-x R/W-x R/W-x R/W-x R/W-x
SID2 SID1 SID0 — EXIDE —EID17EID16
bit 7 bit 0
bit 7-5 SID2:SID0: Standard Identifier bits if EXIDE = 0 or
Extended Identifier bits EID20:EID18 if EXIDE = 1
bit 4 Unimplemented: Read as ‘0’
bit 3 EXIDE: Extended Identifier enable bit
1 = Message will transmit extended ID, SID10:SID0 becomes EID28:EID18
0 = Message will transmit standard ID, EID17:EID0 are ignored
bit 2 Unimplemented: Read as ‘0’
bit 1-0 EID17:EID16: Extended Identifier bits
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
R/W-x R/W-x R/W-x R/W-x R/W-x R/W-x R/W-x R/W-x
EID15 EID14 EID13 EID12 EID11 EID10 EID9 EID8
bit 7 bit 0
bit 7-0 EID15:EID8: Extended Identifier bits
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
