PIC16F872
3.0 DATA EEPROM AND FLASH
PROGRAM MEMORY
The Data EEPROM and FLASH Program Memory are
readable and writable during normal operation over the
entire V
DD range. These operations take place on a sin-
gle byte for Data EEPROM memory and a single word
for Program memory. A write operation causes an
erase-then-write operation to take place on the speci-
fied byte or word. A bulk erase operation may not be
issued from user code (which includes removing code
protection).
Access to program memory allows for checksum calcu-
lation. The values written to Program memory do not
need to be valid instructions. Therefore, numbers of up
to 14 bits can be stored in memory for use as calibra-
tion parameters, serial numbers, packed 7-bit ASCII,
etc. Executing a program memory location, containing
data that forms an invalid instruction, results in the exe-
cution of a NOP instruction.
The EEPROM Data memory is rated for high erase/
write cycles (specification #D120). The FLASH Pro-
gram memory is rated much lower (specification
#D130) because EEPROM Data memory can be used
to store frequently updated values. An on-chip timer
controls the write time and it will vary with voltage and
temperature, as well as from chip to chip. Please refer
to the specifications for exact limits (specifications
#D122 and #D133).
A byte or word write automatically erases the location
and writes the new value (erase before write). Writing
to EEPROM Data memory does not impact the opera-
tion of the device. Writing to Program memory will
cease the execution of instructions until the write is
complete. The program memory cannot be accessed
during the write. During the write operation, the oscilla-
tor continues to run, the peripherals continue to func-
tion and interrupt events will be detected and
essentially “queued” until the write is complete. When
the write completes, the next instruction in the pipeline
is executed and the branch to the interrupt vector will
take place if the interrupt is enabled and occurred dur-
ing the write.
Read and write access to both memories take place
indirectly through a set of Special Function Registers
(SFR). The six SFRs used are:
• EEDATA
• EEDATH
• EEADR
• EEADRH
• EECON1
• EECON2
The EEPROM Data memory allows byte read and write
operations without interfering with the normal operation
of the microcontroller. When interfacing to EEPROM
Data memory, the EEADR register holds the address to
be accessed. Depending on the operation, the EEDATA
register holds the data to be written or the data read at
the address in EEADR. The PIC16F872 has 64 bytes of
EEPROM Data memory and therefore, requires that the
two Most Significant bits of EEADR remain clear.
EEPROM Data memory on these devices wraps around
to 0 (i.e., 40h in the EEADR maps to 00h).
The FLASH Program memory allows non-intrusive
read access, but write operations cause the device to
stop executing instructions until the write completes.
When interfacing to the Program memory, the
EEADRH:EEADR registers pair forms a two-byte word
which holds the 13-bit address of the memory location
being accessed. The EEDATH:EEDATA register pair
holds the 14-bit data for writes or reflects the value of
program memory after a read operation. Just as in
EEPROM Data memory accesses, the value of the
EEADRH:EEADR registers must be within the valid
range of program memory, depending on the device
(0000h to 07FFh). Addresses outside of this range
wrap around to 0000h (i.e., 0800h maps to 0000h).
3.1 EECON1 and EECON2 Registers
The EECON1 register is the control register for config-
uring and initiating the access. The EECON2 register is
not a physically implemented register, but is used
exclusively in the memory write sequence to prevent
inadvertent writes.
There are many bits used to control the read and write
operations to EEPROM Data and FLASH Program
memory. The EEPGD bit determines if the access will
be a program or data memory access. When clear, any
subsequent operations will work on the EEPROM Data
memory. When set, all subsequent operations will
operate in the Program memory.
Read operations only use one additional bit, RD, which
initiates the read operation from the desired memory
location. Once this bit is set, the value of the desired
memory location will be available in the data registers.
This bit cannot be cleared by firmware. It is automati-
cally cleared at the end of the read operation. For
EEPROM Data memory reads, the data will be avail-
able in the EEDATA register in the very next instruction
cycle after the RD bit is set. For program memory
reads, the data will be loaded into the
EEDATH:EEDATA registers, following the second
instruction after the RD bit is set.
