PIC16F627A/628A/648A

DS40044A-page 20 Preliminary  2002 Microchip Technology Inc.

TABLE 4-5: SPECIAL FUNCTION REGISTERS SUMMARY BANK2

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Value on

POR

Reset

(1)

Details

Page

Bank 2

100h INDF Addressing this location uses contents of FSR to address data memory (not a physical register) xxxx xxxx 28

101h TMR0

Timer0 module’s Register xxxx xxxx

102h PCL Program Counter's (PC) Least Significant Byte 0000 0000 28

103h STATUS IRP RP1 RP0 TO

PD ZDCC0001 1xxx

104h FSR Indirect data memory address pointer xxxx xxxx 28

105h — Unimplemented — —

106h PORTB RB7 RB6 RB5 RB4 RB3 RB2 RB1 RB0 xxxx xxxx 36

107h — Unimplemented — —

108h — Unimplemented — —

109h — Unimplemented — —

10Ah PCLATH

— — — Write buffer for upper 5 bits of program counter ---0 0000 28

10Bh INTCON GIE PEIE T0IE INTE RBIE T0IF INTF RBIF 0000 000x 24

10Ch — Unimplemented — —

10Dh — Unimplemented — —

10Eh — Unimplemented — —

10Fh — Unimplemented — —

110h — Unimplemented — —

111h — Unimplemented — —

112h — Unimplemented — —

113h — Unimplemented — —

114h — Unimplemented — —

115h — Unimplemented — —

116h — Unimplemented — —

117h — Unimplemented — —

118h — Unimplemented — —

119h — Unimplemented — —

11Ah — Unimplemented — —

11Bh — Unimplemented — —

11Ch — Unimplemented — —

11Dh — Unimplemented — —

11Eh — Unimplemented — —

11Fh — Unimplemented — —

Legend: — = Unimplemented locations read as ‘0’, u = unchanged, x = unknown, q = value depends on condition, shaded =

unimplemented.

Note 1: For the Initialization Condition for Registers Tables, refer to Table 14-6 and Table 14-7.
