PIC16F627A/628A/648A
DS40044A-page 138 Preliminary 2002 Microchip Technology Inc.
TABLE 17-2: COMPARATOR SPECIFICATIONS
TABLE 17-3: VOLTAGE REFERENCE SPECIFICATIONS
Operating Conditions: 2.0V < VDD <5.5V, -40°C < TA < +125°C, unless otherwise stated.
Param
No.
Characteristics Sym Min Typ Max Units Comments
D300 Input Offset Voltage V
IOFF — ±5.0 ±10 mV
D301 Input Common Mode Voltage V
ICM 0—VDD - 1.5* V
D302 Common Mode Rejection Ratio CMRR 55* — — db
D303 Response Time
(1)
TRESP —
—
—
300
400
400
400*
600*
600*
ns
ns
ns
V
DD = 3.0V to 5.5V
-40° to +85°C
V
DD = 3.0V to 5.5V
-85° to +125°C
V
DD = 2.0V to 3.0V
-40° to +85°C
D304 Comparator Mode Change to
Output Valid
T
MC2OV — 300 10* µs
* These parameters are characterized but not tested.
Note 1: Response time measured with one comparator input at (V
DD - 1.5)/2 while the other input transitions from
V
SS to VDD.
Operating Conditions: 2.0V < V
DD < 5.5V, -40°C < TA < +125°C, unless otherwise stated.
Spec
No.
Characteristics Sym Min Typ Max Units Comments
D310 Resolution V
RES ——VDD/24
V
DD/32
LSb
LSb
Low Range (VRR = 1)
High Range (VRR = 0)
D311 Absolute Accuracy VR
AA —
—
—
—
1/4
(2)
*
1/2
(2)
*
LSb
LSb
Low Range (VRR = 1)
High Range (VRR = 0)
D312 Unit Resistor Value (R) VR
UR —2k*— Ω
D313 Settling Time
(1)
TSET — — 10* µs
* These parameters are characterized but not tested.
Note 1: Settling time measured while VRR = 1 and VR<3:0> transitions from 0000 to 1111.
2: When V
DD is between 2.0V and 3.0V the VREF output voltage levels on RA2 descirbed by the equa-
tion:[V
DD/2 ± (3-VDD)/2] may cause the Absolute Accuracy (VRAA) of the VREF output signal on RA2 to be
greater than the stated max.
