25.3 DC Characteristics: Power-Down Currents (IPD)
PIC16LF1526/7
Standard Operating Conditions (unless otherwise stated)
Operating temperature -40°C  TA  +85°C for industrial
-40°C
 TA  +125°C for extended
PIC16F1526/7
Standard Operating Conditions (unless otherwise stated)
Operating temperature -40°C  TA  +85°C for industrial
-40°C
 TA  +125°C for extended
Param
No.
Device
Characteristics
Min. Typ†
Max.
+85°C
Max.
+125°C
Units
Conditions
V
DD Note
Power-down Currents (I
PD)
(2)
D022 Base IPD — 0.02 1.0 8.0 A 1.8 WDT, BOR, FVR and SOSC disabled,
all peripherals inactive
— 0.03 2.0 9.0
A3.0
D022 Base IPD — 0.20 3.0 10 A 2.3 WDT, BOR, FVR and SOSC disabled,
all peripherals inactive,
Low-power regulator active
— 0.30 4.0 12 A 3.0
— 0.47 6.0 15 A 5.0
D023 — 0.50 6.0 14
A 1.8 WDT Current (Note 1)
— 0.80 7.0 17 A 3.0
D023 — 0.50 6.0 15 A 2.3 WDT Current (Note 1)
VREGPM = 1
— 0.77 7.0 20 A 3.0
— 0.85 8.0 22 A 5.0
D023A
— 8.5 24 27 A 3.0
FVR current
(Note 1)
D023A — 19 27 37 A 3.0 FVR current (Note 1)
VREGPM = 1
— 20 29 45 A 5.0
D024 — 8.0 17 20
A 3.0 BOR Current (Note 1)
D024 — 8.0 17 30 A 3.0 BOR Current (Note 1)
VREGPM = 1
— 9.0 20 40 A 5.0
D024A — 0.30 4.0 8.0
A 3.0 LPBOR Current (Note 1)
D024A — 0.30 4.0 14 A 3.0 LPBOR Current (Note 1)
VREGPM = 1
— 0.45 8.0 17 A 5.0
D025 — 0.3 5.0 9.0
A 1.8 SOSC Current (Note 1)
—0.58.5 12 A3.0
D025 — 1.1 6.0 10 A 2.3 SOSC Current (Note 1)
VREGPM = 1
— 1.3 8.5 20 A 3.0
— 1.4 10 25 A 5.0
D026* — 0.10 1.0 9.0
A 1.8 ADC Current (Note 1, 3),
No conversion in progress
— 0.10 2.0 10
A3.0
D026* — 0.16 3.0 10 A 2.3 ADC Current (Note 1, 3),
No conversion in progress
VREGPM =
1
— 0.40 4.0 11 A 3.0
— 0.50 6.0 16 A 5.0
* These parameters are characterized but not tested.
† Data in “Typ” column is at 3.0V, 25°C unless otherwise stated. These parameters are for design guidance only and are
not tested.
Note 1: The peripheral  current can be determined by subtracting the base IPD current from this limit. Max. values should be
used when calculating total current consumption.
2: The power-down current in Sleep mode does not depend on the oscillator type. Power-down current is measured with
the part in Sleep mode, with all I/O pins in high-impedance state and tied to V
DD.
3: ADC clock source is FRC.
