Datasheet

PIC16(L)F1508/9
DS40001609C-page 338  2011-2013 Microchip Technology Inc.
TABLE 29-8: OSCILLATOR PARAMETERS
FIGURE 29-6: HFINTOSC FREQUENCY ACCURACY OVER V
DD AND TEMPERATURE
Standard Operating Conditions (unless otherwise stated)
Param.
No.
Sym. Characteristic
Freq.
Tolerance
Min. Typ† Max. Units Conditions
OS08 HF
OSC Internal Calibrated HFINTOSC
Frequency
(1)
±2% — 16.0 — MHz VDD = 3.0V, TA = 25°C,
(Note 2)
OS09 LF
OSC Internal LFINTOSC Frequency — — 31 — kHz (Note 3)
OS10* T
IOSC ST HFINTOSC
Wake-up from Sleep Start-up Time
——515s
OS10A* T
LFOSC ST LFINTOSC
Wake-up from Sleep Start-up Time
— — 0.5 — ms -40°C  TA  +125°C
* These parameters are characterized but not tested.
† Data in “Typ” column is at 3.0V, 25°C unless otherwise stated. These parameters are for design guidance only and are
not tested.
Note 1: To ensure these oscillator frequency tolerances, V
DD and VSS must be capacitively decoupled as close to the device as
possible. 0.1 F and 0.01 F values in parallel are recommended.
2: See Figure 29-6: “HFINTOSC Frequency Accuracy over Device V
DD and Temperature”,
Figure 30-73: “HFINTOSC Accuracy Over Temperature, V
DD = 1.8V, PIC16LF1508/9 Only”, and
Figure 30-74: “HFINTOSC Accuracy Over Temperature, 2.3V  V
DD 5.5V”.
3: See Figure 30-71: “LFINTOSC Frequency over V
DD and Temperature, PIC16LF1508/9 Only”, and
Figure 30-72: “ LFINTOSC Frequency over V
DD and Temperature, PIC16F1508/9”.
VDD (V)
125
85
60
25
0
-40
1.8 2.3 5.5
±4.5%
-4.5% to +7%
±12%
±12%
Temperature (°C)
Rev. 10-000135A
7/30/2013
Note: See Figure 30-73: “HFINTOSC Accuracy Over Temperature, VDD = 1.8V, PIC16LF1508/9 Only”,
and Figure 30-74: “HFINTOSC Accuracy Over Temperature, 2.3V V
DD  5.5V”.
