D025 — 0.7 4.0 9.0 A 1.8 SOSC Current
—2.38.0 12 A3.0
D025 — 1.0 6.0 11 A 2.3 SOSC Current
— 2.4 8.5 20 A 3.0
— 6.9 20 25 A 5.0
D026 — 0.11 1.5 9.0 A 1.8 ADC Current (Note 3),
No conversion in progress
— 0.12 2.7 10 A3.0
D026 — 0.30 4.0 11 A 2.3 ADC Current (Note 3),
No conversion in progress
— 0.35 5.0 13 A 3.0
— 0.45 8.0 16 A 5.0
D026A* — 250 — — A 1.8 ADC Current (Note 3),
Conversion in progress
—250 — — A3.0
D026A* — 280 — — A 2.3 ADC Current (Note 3),
Conversion in progress
— 280 — — A 3.0
— 280 — — A 5.0
D027 — 7 22 25 A 1.8 Comparator,
CxSP = 0
— 8 23 27 A3.0
D027 — 17 35 37 A 2.3 Comparator,
CxSP = 0
— 18 37 38 A 3.0
— 19 38 40 A 5.0
TABLE 29-3: POWER-DOWN CURRENTS (IPD)
(1,2)
(CONTINUED)
PIC16LF1508/9
Operating Conditions: (unless otherwise stated)
Low-Power Sleep Mode
PIC16F1508/9
Low-Power Sleep Mode, VREGPM = 1
Param.
No.
Device Characteristics Min. Typ†
Max.
+85°C
Max.
+125°C
Units
Conditions
V
DD Note
* These parameters are characterized but not tested.
† Data in “Typ” column is at 3.0V, 25°C unless otherwise stated. These parameters are for design guidance only and are
not tested.
Note 1: The peripheral  current can be determined by subtracting the base I
PD current from this limit. Max. values should be
used when calculating total current consumption.
2: The power-down current in Sleep mode does not depend on the oscillator type. Power-down current is measured with
the part in Sleep mode, with all I/O pins in high-impedance state and tied to V
SS.
3: ADC clock source is FRC.
