20-Pin Flash, 8-Bit Microcontrollers with XLP Technology
PIC12(L)F1501/PIC16(L)F150X Family Types
Pin Diagrams
Pin Allocation Table
TABLE 1: 20-Pin Allocation Table (PIC16(L)F1508/9)
Table of Contents
1.0 Device Overview
- TABLE 1-1: Device Peripheral Summary
- FIGURE 1-1: PIC16(L)F1508/9 Block Diagram
- TABLE 1-2: PIC16(L)F1508/9 Pinout Description
2.0 Enhanced Mid-Range CPU
- FIGURE 2-1: Core Block Diagram
3.0 Memory Organization
- TABLE 3-1: Device Sizes and Addresses
- FIGURE 3-1: Program Memory Map And Stack For PIC16(L)F1508
- FIGURE 3-2: Program Memory Map And Stack For PIC16(L)F1509
  - EXAMPLE 3-1: RETLW Instruction
  - EXAMPLE 3-2: Accessing Program Memory Via FSR
  - 3.2 Data Memory Organization
- TABLE 3-2: Core Registers
  - Register 3-1: STATUS: STATUS Register
- FIGURE 3-3: Banked Memory Partitioning
- TABLE 3-3: PIC16(L)F1509 Memory Map, Bank 1-7
- TABLE 3-4: PIC16(L)F1508 Memory Map, Bank 1-7
- TABLE 3-5: PIC16(L)F1508/9 Memory Map, Bank 8-23
- 3.1 Program Memory Organization
- FIGURE 3-11: Linear Data Memory Map
- TABLE 3-6: PIC16(L)F1508/9 Memory Map, Bank 24-31
- TABLE 3-7: PIC16(L)F1508/9 Memory Map, Bank 30-31
- TABLE 3-8: Core Function Registers Summary
- TABLE 3-9: Special Function Register Summary
  - 3.3 PCL and PCLATH
- FIGURE 3-4: Loading of PC in Different Situations
  - 3.4 Stack
- FIGURE 3-5: Accessing the Stack Example 1
- FIGURE 3-6: Accessing the Stack Example 2
- FIGURE 3-7: Accessing the Stack Example 3
- FIGURE 3-8: Accessing the Stack Example 4
  - 3.5 Indirect Addressing
- FIGURE 3-9: Indirect Addressing
- FIGURE 3-10: Traditional Data Memory Map
- FIGURE 3-12: Program Flash Memory Map
4.0 Device Configuration
- 4.1 Configuration Words
- 4.2 Register Definitions: Configuration Words
- Register 4-1: CONFIG1: Configuration Word 1
- Register 4-2: CONFIG2: Configuration Word 2
- 4.3 Code Protection
- 4.4 Write Protection
- 4.5 User ID
- 4.6 Device ID and Revision ID
- 4.7 Register Definitions: Device ID
- Register 4-3: DEVID: Device ID Register
5.0 Oscillator Module (With Fail-Safe Clock Monitor)
- FIGURE 5-1: Simplified PIC® MCU Clock Source Block Diagram
  - 5.2 Clock Source Types
- FIGURE 5-2: External Clock (EC) Mode Operation
- FIGURE 5-3: Quartz Crystal Operation (LP, XT or HS Mode)
- FIGURE 5-4: Ceramic Resonator Operation (XT or HS Mode)
- FIGURE 5-5: Quartz Crystal Operation (Secondary Oscillator)
- FIGURE 5-6: External RC Modes
- TABLE 5-1: Peripheral Clock Sources
- FIGURE 5-7: Internal Oscillator Switch Timing
  - 5.3 Clock Switching
- TABLE 5-2: OSTS Bit Definition
  - 5.4 Two-Speed Clock Start-up Mode
- TABLE 5-3: Oscillator Switching Delays
- FIGURE 5-8: Two-Speed Start-up
  - 5.5 Fail-Safe Clock Monitor
- FIGURE 5-9: FSCM Block Diagram
- FIGURE 5-10: FSCM Timing Diagram
- TABLE 5-4: Summary of Registers Associated with Clock Sources
- 5.1 Overview
- TABLE 5-5: Summary of Configuration Word with Clock Sources
6.0 Resets
- FIGURE 6-1: Simplified Block Diagram of On-Chip Reset Circuit
  - 6.1 Power-On Reset (POR)
  - 6.2 Brown-Out Reset (BOR)
- TABLE 6-1: BOR Operating Modes
- FIGURE 6-2: Brown-out Situations
- TABLE 6-2: MCLR Configuration
- FIGURE 6-3: Reset Start-up Sequence
  - 6.12 Determining the Cause of a Reset
- TABLE 6-3: Reset Status Bits and Their Significance
- TABLE 6-4: Reset Condition for Special Registers
- TABLE 6-5: Summary of Registers Associated with Resets
- TABLE 6-6: Summary of Configuration Word with Resets
7.0 Interrupts
- FIGURE 7-1: Interrupt Logic
  - 7.1 Operation
  - 7.2 Interrupt Latency
- FIGURE 7-2: Interrupt Latency
- FIGURE 7-3: INT Pin Interrupt Timing
- TABLE 7-1: Summary of Registers Associated with Interrupts
8.0 Power-Down Mode (Sleep)
- FIGURE 8-1: Wake-up from Sleep through Interrupt
- TABLE 8-1: Summary of Registers Associated with Power-Down Mode
- 8.1 Wake-up from Sleep
9.0 Watchdog Timer (WDT)
- FIGURE 9-1: Watchdog Timer Block Diagram
  - 9.1 Independent Clock Source
  - 9.2 WDT Operating Modes
- TABLE 9-1: WDT Operating Modes
- TABLE 9-2: WDT Clearing Conditions
  - 9.6 Register Definitions: Watchdog Control
  - Register 9-1: WDTCON: Watchdog Timer Control Register
- TABLE 9-3: Summary of Registers Associated with Watchdog Timer
- TABLE 9-4: Summary of Configuration Word with Watchdog Timer
10.0 Flash Program Memory Control
- TABLE 10-1: Flash Memory Organization by Device
- FIGURE 10-1: Flash Program Memory Read Flowchart
- FIGURE 10-2: Flash Program Memory Read Cycle Execution
  - EXAMPLE 10-1: Flash Program Memory Read
- FIGURE 10-3: Flash Program Memory Unlock Sequence Flowchart
- FIGURE 10-4: Flash Program Memory Erase Flowchart
  - EXAMPLE 10-2: Erasing One Row of Program Memory
- FIGURE 10-5: Block Writes to Flash Program Memory with 32 Write latches
- FIGURE 10-6: Flash Program Memory Write Flowchart
  - EXAMPLE 10-3: Writing to Flash Program Memory (32 Write Latches)
  - 10.3 Modifying Flash Program Memory
- FIGURE 10-7: Flash Program Memory Modify Flowchart
  - 10.4 User ID, Device ID and Configuration Word Access
- TABLE 10-2: User ID, Device ID and Configuration Word Access (CFGS = 1)
  - EXAMPLE 10-4: Configuration Word and Device ID Access
  - 10.5 Write Verify
- 10.1 PMADRL and PMADRH Registers
- 10.2 Flash Program Memory Overview
- FIGURE 10-8: Flash Program Memory Verify Flowchart
- TABLE 10-3: Summary of Registers Associated with Flash Program Memory
- TABLE 10-4: Summary of Configuration Word with Flash Program Memory
11.0 I/O Ports
- TABLE 11-1: Port Availability Per Device
- FIGURE 11-1: Generic I/O Port Operation
- TABLE 11-2: PORTA Output Priority
- TABLE 11-3: Summary of Registers Associated with PORTA
- TABLE 11-4: Summary of Configuration Word with PORTA
  - 11.5 PORTB Registers
- TABLE 11-5: PORTB Output Priority
- TABLE 11-6: Summary of Registers Associated with PORTB
- TABLE 11-7: Summary of Configuration Word with PORTB
  - 11.7 PORTC Registers
- TABLE 11-8: PORTC Output Priority
- TABLE 11-9: Summary of Registers Associated with PORTC
12.0 Interrupt-On-Change
- FIGURE 12-1: Interrupt-On-Change Block Diagram (PORTA Example)
- TABLE 12-1: Summary of Registers Associated with Interrupt-on-Change
- 12.1 Enabling the Module
- 12.2 Individual Pin Configuration
- 12.3 Interrupt Flags
- 12.4 Clearing Interrupt Flags
- EXAMPLE 12-1: Clearing Interrupt Flags (PORTA Example)
- 12.5 Operation in Sleep
13.0 Fixed Voltage Reference (FVR)
- FIGURE 13-1: Voltage Reference Block Diagram
- TABLE 13-1: Peripherals Requiring the Fixed Voltage Reference (FVR)
  - 13.3 Register Definitions: FVR Control
  - Register 13-1: FVRCON: Fixed Voltage Reference Control Register
- TABLE 13-2: Summary of Registers Associated with the Fixed Voltage Reference
- 13.1 Independent Gain Amplifier
- 13.2 FVR Stabilization Period
14.0 Temperature Indicator Module
- FIGURE 14-1: Temperature Circuit Diagram
  - 14.2 Minimum Operating Vdd
- TABLE 14-1: Recommended Vdd vs. Range
  - 14.3 Temperature Output
  - 14.4 ADC Acquisition Time
- TABLE 14-2: Summary of Registers Associated with the Temperature Indicator
- 14.1 Circuit Operation
- EQUATION 14-1: Vout Ranges
15.0 Analog-to-Digital Converter (ADC) Module
- FIGURE 15-1: ADC Block Diagram
  - 15.1 ADC Configuration
- TABLE 15-1: ADC Clock Period (Tad) Vs. Device Operating Frequencies
- FIGURE 15-2: Analog-to-Digital Conversion Tad Cycles
- FIGURE 15-3: 10-Bit ADC Conversion Result Format
  - 15.2 ADC Operation
- TABLE 15-2: Auto-Conversion Sources
- FIGURE 15-4: Analog Input Model
- FIGURE 15-5: ADC Transfer Function
- TABLE 15-3: Summary of Registers Associated with ADC
16.0 5-Bit Digital-to-Analog Converter (DAC) Module
- FIGURE 16-1: Digital-to-Analog Converter Block Diagram
- TABLE 16-1: Summary of Registers Associated with the DAC Module
17.0 Comparator Module
- TABLE 17-1: Available Comparators
- FIGURE 17-1: Comparator Module Simplified Block Diagram
- FIGURE 17-2: Single Comparator
  - 17.2 Comparator Control
- TABLE 17-2: Comparator Output State vs. Input Conditions
  - 17.3 Analog Input Connection Considerations
- FIGURE 17-3: Analog Input Model
- FIGURE 17-4: Analog Input Model
- TABLE 17-3: Summary of Registers Associated with Comparator Module
- 17.1 Comparator Overview
18.0 Timer0 Module
- FIGURE 18-1: Timer0 Block Diagram
  - 18.2 Register Definitions: Option Register
  - Register 18-1: OPTION_REG: OPTION Register
- TABLE 18-1: Summary of Registers Associated with Timer0
- 18.1 Timer0 Operation
19.0 Timer1 Module with Gate Control
- FIGURE 19-1: Timer1 Block Diagram
  - 19.1 Timer1 Operation
- TABLE 19-1: Timer1 Enable Selections
  - 19.2 Clock Source Selection
- TABLE 19-2: Clock Source Selections
- TABLE 19-3: Timer1 Gate Enable Selections
- TABLE 19-4: Timer1 Gate Sources
  - 19.7 Timer1 Interrupt
  - 19.8 Timer1 Operation During Sleep
- FIGURE 19-2: Timer1 Incrementing Edge
- FIGURE 19-3: Timer1 Gate Enable Mode
- FIGURE 19-4: Timer1 Gate Toggle Mode
- FIGURE 19-5: Timer1 Gate Single-Pulse Mode
- FIGURE 19-6: Timer1 Gate Single-Pulse and Toggle Combined Mode
- TABLE 19-5: Summary of Registers Associated with Timer1
20.0 Timer2 Module
- FIGURE 20-1: Timer2 Block Diagram
- FIGURE 20-2: Timer2 Timing Diagram
- FIGURE 20-3: T2_match Timing Diagram
- TABLE 20-1: Summary of Registers Associated With Timer2
21.0 Master Synchronous Serial Port (MSSP) Module
- FIGURE 21-1: MSSP Block Diagram (SPI mode)
- FIGURE 21-2: MSSPx Block Diagram (I2C™ Master mode)
- FIGURE 21-3: MSSP Block Diagram (I2C™ Slave mode)
  - 21.2 SPI Mode Overview
- FIGURE 21-4: SPI Master and Multiple Slave Connection
- FIGURE 21-5: SPI Master/Slave Connection
- FIGURE 21-6: SPI Mode Waveform (Master Mode)
- FIGURE 21-7: SPI Daisy-Chain Connection
- FIGURE 21-8: Slave Select Synchronous Waveform
- FIGURE 21-9: SPI Mode Waveform (Slave Mode With CKE = 0)
- FIGURE 21-10: SPI Mode Waveform (SLAve Mode With CKE = 1)
- 21.1 MSSP Module Overview
- TABLE 21-1: Summary of Registers Associated with SPI Operation
  - 21.3 I2C Mode Overview
- FIGURE 21-11: I2C Master/ Slave Connection
  - 21.4 I2C Mode Operation
- TABLE 21-2: I2C Bus terms
- FIGURE 21-12: I2C Start and Stop Conditions
- FIGURE 21-13: I2C Restart Condition
  - 21.5 I2C Slave Mode Operation
- FIGURE 21-14: I2C Slave, 7-bit Address, Reception (SEN = 0, AHEN = 0, DHEN = 0)
- FIGURE 21-15: I2C Slave, 7-bit Address, Reception (SEN = 1, AHEN = 0, DHEN = 0)
- FIGURE 21-16: I2C Slave, 7-bit Address, Reception (SEN = 0, AHEN = 1, DHEN = 1)
- FIGURE 21-17: I2C Slave, 7-bit Address, Reception (SEN = 1, AHEN = 1, DHEN = 1)
- FIGURE 21-18: I2C Slave, 7-bit Address, Transmission (AHEN = 0)
- FIGURE 21-19: I2C Slave, 7-bit Address, Transmission (AHEN = 1)
- FIGURE 21-20: I2C Slave, 10-bit Address, Reception (SEN = 1, AHEN = 0, DHEN = 0)
- FIGURE 21-21: I2C Slave, 10-bit Address, Reception (SEN = 0, AHEN = 1, DHEN = 0)
- FIGURE 21-22: I2C Slave, 10-bit Address, Transmission (SEN = 0, AHEN = 0, DHEN = 0)
- FIGURE 21-23: Clock Synchronization Timing
- FIGURE 21-24: Slave Mode General Call Address Sequence
  - 21.6 I2C Master Mode
- FIGURE 21-25: Baud Rate Generator Timing with Clock Arbitration
- FIGURE 21-26: First Start Bit Timing
- FIGURE 21-27: Repeat Start Condition Waveform
- FIGURE 21-28: I2C Master Mode Waveform (Transmission, 7 or 10-bit Address)
- FIGURE 21-29: I2C Master Mode Waveform (Reception, 7-bit Address)
- FIGURE 21-30: Acknowledge Sequence Waveform
- FIGURE 21-31: Stop Condition Receive or Transmit Mode
- FIGURE 21-32: Bus Collision Timing for Transmit and Acknowledge
- FIGURE 21-33: Bus Collision During Start Condition (SDAx Only)
- FIGURE 21-34: Bus Collision During Start Condition (SCLx = 0)
- FIGURE 21-35: BRG Reset Due to SDA Arbitration During Start Condition
- FIGURE 21-36: Bus Collision During a Repeated Start Condition (Case 1)
- FIGURE 21-37: Bus Collision During Repeated Start Condition (Case 2)
- FIGURE 21-38: Bus Collision During a Stop Condition (Case 1)
- FIGURE 21-39: Bus Collision During a Stop Condition (Case 2)
- TABLE 21-3: Summary of Registers Associated with I2C™ Operation
  - 21.7 Baud Rate Generator
- FIGURE 21-40: Baud Rate Generator Block Diagram
- TABLE 21-4: MSSP Clock Rate w/BRG
  - 21.8 Register Definitions: MSSP Control
  - Register 21-1: SSPxSTAT: SSP STATUS Register
  - Register 21-2: SSPxCON1: SSP Control Register 1
  - Register 21-3: SSPxCON2: SSP Control Register 2(1)
  - Register 21-4: SSPxCON3: SSP Control Register 3
  - Register 21-5: SSPxMSK: SSP Mask Register
  - Register 21-6: SSPxADD: MSSP Address and Baud Rate Register (I2C Mode)
22.0 Enhanced Universal Synchronous Asynchronous Receiver Transmitter (EUSART)
- FIGURE 22-1: EUSART Transmit Block Diagram
- FIGURE 22-2: EUSART Receive Block Diagram
  - 22.1 EUSART Asynchronous Mode
- FIGURE 22-3: Asynchronous Transmission
- FIGURE 22-4: Asynchronous Transmission (Back-to-Back)
- TABLE 22-1: Summary of Registers Associated with Asynchronous Transmission
- FIGURE 22-5: Asynchronous Reception
- TABLE 22-2: Summary of Registers Associated with Asynchronous Reception
  - 22.2 Clock Accuracy with Asynchronous Operation
  - 22.3 Register Definitions: EUSART Control
  - Register 22-1: TXSTA: Transmit Status and Control Register
  - Register 22-2: RCSTA: Receive Status and Control Register
  - Register 22-3: BAUDCON: Baud Rate Control Register
  - 22.4 EUSART Baud Rate Generator (BRG)
  - EXAMPLE 22-1: Calculating Baud Rate Error
- TABLE 22-3: Baud Rate Formulas
- TABLE 22-4: Summary of Registers Associated with the Baud Rate Generator
- TABLE 22-5: BAUD Rates for Asynchronous Modes
- TABLE 22-6: BRG Counter Clock Rates
- FIGURE 22-6: Automatic Baud Rate Calibration
- FIGURE 22-7: Auto-Wake-up Bit (WUE) Timing During Normal Operation
- FIGURE 22-8: Auto-Wake-up Bit (WUE) Timings During Sleep
- FIGURE 22-9: Send Break Character Sequence
  - 22.5 EUSART Synchronous Mode
- FIGURE 22-10: Synchronous Transmission
- FIGURE 22-11: Synchronous Transmission (Through TXEN)
- TABLE 22-7: Summary of Registers Associated with Synchronous Master Transmission
- FIGURE 22-12: Synchronous Reception (Master Mode, SREN)
- TABLE 22-8: Summary of Registers Associated with Synchronous Master Reception
- TABLE 22-9: Summary of Registers Associated with Synchronous Slave Transmission
- TABLE 22-10: Summary of Registers Associated with Synchronous Slave Reception
23.0 Pulse Width Modulation (PWM) Module
- FIGURE 23-1: Simplified PWM Block Diagram
- FIGURE 23-2: PWM Output
  - EQUATION 23-4: PWM Resolution
- TABLE 23-1: Example PWM Frequencies and Resolutions (Fosc = 20 MHz)
- TABLE 23-2: Example PWM Frequencies and Resolutions (Fosc = 8 MHz)
- TABLE 23-3: Summary of Registers Associated with PWM
24.0 Configurable Logic Cell (CLC)
- FIGURE 24-1: Digital-to-Analog Converter Block Diagram
  - 24.1 CLCx Setup
- TABLE 24-1: CLCx Data Input Selection
- TABLE 24-2: Data Gating Logic
- FIGURE 24-2: Input Data Selection and Gating
- FIGURE 24-3: Programmable Logic Functions
- TABLE 24-3: Summary of Registers Associated with CLCx
25.0 Numerically Controlled Oscillator (NCO) Module
- FIGURE 25-1: Numerically Controlled Oscillator (NCOx) Module Simplified Block Diagram
- FIGURE 25-2: NCO – Fixed Duty Cycle (FDC) and Pulse Frequency Mode (PFM) Output Operation Diagram
- TABLE 25-1: Summary of Registers Associated with NCOx
- 25.1 NCOx Operation
- EQUATION 25-1:
26.0 Complementary Waveform Generator (CWG) Module
- TABLE 26-1: Selectable Input Sources
  - 26.4 Output Control
- FIGURE 26-1: Simplified CWG Block Diagram
- FIGURE 26-2: Typical CWG Operation with PWM1 (No Auto-shutdown)
- FIGURE 26-3: Dead-Band Operation, CWGxDBR = 01H, CWGxDBF = 02H
- FIGURE 26-4: Dead-Band Operation, CWGxDBR = 03H, CWGxDBF = 04H, Source Shorter Than Dead Band
- FIGURE 26-5: Shutdown Functionality, Auto-Restart Disabled (GxARSEN = 0,GxASDLA = 01, GxASDLB = 01)
- FIGURE 26-6: Shutdown Functionality, Auto-Restart Enabled (GxARSEN = 1,GxASDLA = 01, GxASDLB = 01)
- 26.1 Fundamental Operation
- 26.2 Clock Source
- 26.3 Selectable Input Sources
- TABLE 26-2: Summary of Registers Associated with CWG
27.0 In-Circuit Serial Programming™ (ICSP™)
- FIGURE 27-1: ICD RJ-11 Style Connector Interface
- FIGURE 27-2: PICkit™ Programmer Style Connector Interface
- FIGURE 27-3: Typical connection for ICSP™ Programming
- 27.1 High-Voltage Programming Entry Mode
- 27.2 Low-Voltage Programming Entry Mode
- 27.3 Common Programming Interfaces
28.0 Instruction Set Summary
- TABLE 28-1: Opcode Field Descriptions
- TABLE 28-2: Abbreviation Descriptions
- FIGURE 28-1: General Format for Instructions
- TABLE 28-3: Enhanced Mid-Range Instruction Set
- TABLE 28-3: Enhanced Mid-Range Instruction Set (Continued)
  - 28.2 Instruction Descriptions
- 28.1 Read-Modify-Write Operations
29.0 Electrical Specifications
- FIGURE 29-13: ADC Conversion Timing (ADC Clock from FRC)
  - FIGURE 29-15: USART Synchronous Receive (Master/Slave) Timing
  - TABLE 29-18: USART Synchronous Receive Requirements
  - FIGURE 29-16: SPI Master Mode Timing (CKE = 0, SMP = 0)
  - FIGURE 29-17: SPI Master Mode Timing (CKE = 1, SMP = 1)
  - FIGURE 29-18: SPI Slave Mode Timing (CKE = 0)
  - FIGURE 29-19: SPI Slave Mode Timing (CKE = 1)
  - TABLE 29-19: SPI Mode requirements
  - FIGURE 29-20: I2C™ Bus Start/Stop Bits Timing
  - TABLE 29-20: I2C™ Bus Start/Stop Bits Requirements
  - FIGURE 29-21: I2C™ Bus Data Timing
    - TABLE 29-21: I2C™ Bus Data Requirements
- TABLE 29-14: ADC Conversion Requirements
- TABLE 29-15: Comparator Specifications(1)
- TABLE 29-16: Digital-to-Analog Converter (DAC) Specifications(1)
- FIGURE 29-14: USART Synchronous Transmission (Master/Slave) Timing
- TABLE 29-17: USART Synchronous Transmission Requirements
- FIGURE 29-1: Voltage Frequency Graph, -40°C £ Ta £ +125°C, PIC16F1508/9 only
- FIGURE 29-2: Voltage Frequency Graph, -40°C £ Ta £ +125°C, PIC16LF1508/9 only
  - 29.3 DC Characteristics
- TABLE 29-1: Supply Voltage
- FIGURE 29-3: POR and POR Rearm with Slow Rising Vdd
- TABLE 29-2: Supply Current (Idd)(1,2)
- TABLE 29-3: Power-Down Currents (Ipd)(1,2)
- TABLE 29-4: I/O Ports
- TABLE 29-5: Memory Programming Specifications
- TABLE 29-6: Thermal Characteristics
  - 29.4 AC Characteristics
- FIGURE 29-4: Load Conditions
- FIGURE 29-5: Clock Timing
- TABLE 29-7: Clock Oscillator Timing Requirements
- TABLE 29-8: Oscillator Parameters
- 29.1 Absolute Maximum Ratings(†)
- 29.2 Standard Operating Conditions
- FIGURE 29-6: HFINTOSC Frequency Accuracy Over Vdd and Temperature
- FIGURE 29-7: CLKOUT and I/O Timing
- TABLE 29-9: CLKOUT and I/O Timing Parameters
- FIGURE 29-8: Reset, Watchdog Timer, Oscillator Start-up Timer and Power-up Timer Timing
- TABLE 29-10: Reset, Watchdog Timer, Oscillator Start-up Timer, Power-up Timer and Brown-Out Reset Parameters
- FIGURE 29-9: Brown-Out Reset Timing and Characteristics
- FIGURE 29-10: Timer0 and Timer1 External Clock Timings
- TABLE 29-11: Timer0 and Timer1 External Clock Requirements
- FIGURE 29-11: CLC Propagation Timing
- TABLE 29-12: Configuration Logic Cell (CLC) Characteristics
- TABLE 29-13: Analog-to-Digital Converter (ADC) Characteristics(1,2,3)
- FIGURE 29-12: ADC Conversion Timing (ADC Clock Fosc-based)
30.0 DC and AC Characteristics Graphs and Charts
- FIGURE 30-1: Idd, LP Oscillator, Fosc = 32 kHz, PIC16LF1508/9 ONLY
- FIGURE 30-2: Idd, LP Oscillator, Fosc = 32 kHz, PIC16F1508/9 ONLY
- FIGURE 30-3: Idd Typical, XT and EXTRC Oscillator, PIC16LF1508/9 ONLY
- FIGURE 30-4: Idd Maximum, XT and EXTRC Oscillator, PIC16LF1508/9 ONLY
- FIGURE 30-5: Idd Typical, XT and EXTRC Oscillator, PIC16F1508/9 ONLY
- FIGURE 30-6: Idd Maximum, XT and EXTRC Oscillator, PIC16F1508/9 ONLY
- FIGURE 30-7: Idd, External Clock (ECL), Low-Power Mode, Fosc = 32 kHz, PIC16LF1508/9 ONLY
- FIGURE 30-8: Idd, External Clock (ECL), Low-Power Mode, Fosc = 32 kHz, PIC16F1508/9 ONLY
- FIGURE 30-9: Idd, External Clock (ECL), Low-Power Mode, Fosc = 500 kHz, PIC16LF1508/9 ONLY
- FIGURE 30-10: Idd, External Clock (ECL), Low-Power Mode, Fosc = 500 kHz, PIC16F1508/9 ONLY
- FIGURE 30-13: Idd Typical, External Clock (ECM), Medium-Power Mode, PIC16F1508/9 ONLY
- FIGURE 30-14: Idd Maximum, External Clock (ECM), Medium-Power Mode, PIC16F1508/9 ONLY
- FIGURE 30-15: Idd Typical, External Clock (ECH), High-Power Mode, PIC16LF1508/9 ONLY
- FIGURE 30-16: Idd Maximum, External Clock (ECH), High-Power Mode, PIC16LF1508/9 ONLY
- FIGURE 30-17: Idd Typical, External Clock (ECH), High-Power Mode, PIC16F1508/9 ONLY
- FIGURE 30-18: Idd Maximum, External Clock (ECH), High-Power Mode, PIC16F1508/9 ONLY
- FIGURE 30-12: Idd Maximum, External Clock (ECM), Medium-Power Mode, PIC16LF1508/9 ONLY
- FIGURE 30-11: Idd Typical, External Clock (ECM), Medium-Power Mode, PIC16LF1508/9 ONLY
- FIGURE 30-19: Idd, LFINTOSC, Fosc = 31 kHz, PIC16LF1508/9 Only
- FIGURE 30-20: Idd, LFINTOSC, Fosc = 31 kHz, PIC16F1508/9 Only
- FIGURE 30-21: Idd, MFINTOSC, Fosc = 500 kHz, PIC16LF1508/9 ONLY
- FIGURE 30-22: Idd, MFINTOSC, Fosc = 500 kHz, PIC16F1508/9 ONLY
- FIGURE 30-23: Idd Typical, HFINTOSC, PIC16LF1508/9 ONLY
- FIGURE 30-24: Idd Maximum, HFINTOSC, PIC16LF1508/9 ONLY
- FIGURE 30-25: Idd Typical, HFINTOSC, PIC16F1508/9 ONLY
- FIGURE 30-26: Idd Maximum, HFINTOSC, PIC16F1508/9 ONLY
- FIGURE 30-27: Idd Typical, HS OScillator, PIC16LF1508/9 ONLY
- FIGURE 30-28: Idd Maximum, HS Oscillator, PIC16LF1508/9 ONLY
- FIGURE 30-29: Idd Typical, HS Oscillator, PIC16F1508/9 ONLY
- FIGURE 30-30: Idd Maximum, HS Oscillator, PIC16F1508/9 ONLY
- FIGURE 30-31: Ipd Base, Low-Power Sleep Mode, PIC16LF1508/9 ONly
- FIGURE 30-32: Ipd Base, Low-Power Sleep Mode, VREGPM = 1, PIC16F1508/9 ONLy
- FIGURE 30-33: Ipd, Watchdog Timer (WDT), PIC16LF1508/9 ONLy
- FIGURE 30-34: Ipd, Watchdog Timer (WDT), PIC16F1508/9 ONLy
- FIGURE 30-35: Ipd, Fixed Voltage Reference (FVR), PIC16LF1508/9 ONLy
- FIGURE 30-36: Ipd, Fixed Voltage Reference (FVR), PIC16F1508/9 ONLy
- FIGURE 30-37: Ipd, Brown-Out Reset (BOR), BORV = 0, PIC16LF1508/9 ONLY
- FIGURE 30-38: Ipd, Brown-Out Reset (BOR), BORV = 1, PIC16LF1508/9 Only
- FIGURE 30-39: Ipd, Brown-Out Reset (BOR), BORV = 0, PIC16F1508/9 Only
- FIGURE 30-40: Ipd, Brown-Out Reset (BOR), BORV = 1, PIC16F1508/9 Only
- FIGURE 30-41: Ipd, Secondary Oscillator, Fosc = 32 kHz, PIC16LF1508/9 Only
- FIGURE 30-42: Ipd, Secondary Oscillator, Fosc = 32 kHz, PIC16F1508/9 Only
- FIGURE 30-43: Ipd, Comparator, Low-Power Mode (CxSP = 0), PIC16LF1508/9 Only
- FIGURE 30-44: Ipd, Comparator, Low-Power Mode (CxSP = 0), PIC16F1508/9 Only
- FIGURE 30-45: Ipd, Comparator, Normal-Power Mode (CxSP = 1), PIC16LF1508/9 Only
- FIGURE 30-46: Ipd, Comparator, Normal-Power Mode (CxSP = 1), PIC16F1508/9 Only
- FIGURE 30-47: Voh vs. Ioh over Temperature, Vdd = 5.5V, PIC16F1508/9 Only
- FIGURE 30-48: Vol vs. Iol over Temperature, Vdd = 5.5V, PIC16F1508/9 Only
- FIGURE 30-49: Voh vs. Ioh over Temperature, Vdd = 3.0V
- FIGURE 30-50: Vol vs. Iol over Temperature, Vdd = 3.0V
- FIGURE 30-51: Voh vs. Ioh over Temperature, Vdd = 1.8V, PIC16LF1508/9 Only
- FIGURE 30-52: Vol vs. Iol over Temperature, Vdd = 1.8V, PIC16LF1508/9 Only
- FIGURE 30-53: POR Release Voltage
- FIGURE 30-54: POR Rearm Voltage, PIC16F1508/9 Only
- FIGURE 30-55: Brown-Out Reset Voltage, BORV = 1, PIC16LF1508/9 Only
- FIGURE 30-56: Brown-Out Reset Hysteresis, BORV = 1, PIC16LF1508/9 Only
- FIGURE 30-57: Brown-Out Reset Voltage, BORV = 1, PIC16F1508/9 Only
- FIGURE 30-58: Brown-Out Reset Hysteresis, BORV = 1, PIC16F1508/9 Only
- FIGURE 30-59: Brown-Out Reset Voltage, BORV = 0
- FIGURE 30-60: Brown-Out Reset Hysteresis, BORV = 0
- FIGURE 30-61: Low-Power Brown-Out Reset Voltage, LPBOR = 0
- FIGURE 30-62: Low-Power Brown-Out Reset Hysteresis, LPBOR = 0
- FIGURE 30-63: WDT Time-Out Period
- FIGURE 30-64: PWRT Period
- FIGURE 30-65: FVR Stabilization Period
- FIGURE 30-66: Comparator Hysteresis, Normal-Power Mode (CxSP = 1, CxHYS = 1)
- FIGURE 30-67: Comparator Hysteresis, Low-Power Mode (CxSP = 0, CxHYS = 1)
- FIGURE 30-68: Comparator Response Time, Normal-Power Mode (CxSP = 1)
- FIGURE 30-69: Comparator Response Time Over Temperature, Normal-Power Mode (CxSP = 1)
- FIGURE 30-70: Comparator Input Offset at 25°C, Normal-Power Mode (CxSP = 1), PIC16F1508/9 Only
- FIGURE 30-71: LFINTOSC Frequency Over Vdd and Temperature, PIC16LF1508/9 Only
- FIGURE 30-72: LFINTOSC Frequency Over Vdd and Temperature, PIC16F1508/9 Only
- FIGURE 30-73: HFINTOSC Accuracy Over Temperature, Vdd = 1.8V, PIC16LF1508/9 Only
- FIGURE 30-74: HFINTOSC Accuracy Over Temperature, 2.3V £ Vdd £ 5.5V
- FIGURE 30-75: Sleep Mode, Wake Period with HFINTOSC Source, PIC16LF1508/9 Only
- FIGURE 30-76: Low-Power Sleep Mode, Wake Period with HFINTOSC Source, VREGPM = 1, PIC16F1508/9 Only
- FIGURE 30-77: Sleep Mode, Wake Period with HFINTOSC Source, VREGPM = 0, PIC16F1508/9 Only
31.0 Development Support
- 31.1 MPLAB X Integrated Development Environment Software
- 31.2 MPLAB XC Compilers
- 31.3 MPASM Assembler
- 31.4 MPLINK Object Linker/ MPLIB Object Librarian
- 31.5 MPLAB Assembler, Linker and Librarian for Various Device Families
- 31.6 MPLAB X SIM Software Simulator
- 31.7 MPLAB REAL ICE In-Circuit Emulator System
- 31.8 MPLAB ICD 3 In-Circuit Debugger System
- 31.9 PICkit 3 In-Circuit Debugger/ Programmer
- 31.10 MPLAB PM3 Device Programmer
- 31.11 Demonstration/Development Boards, Evaluation Kits, and Starter Kits
- 31.12 Third-Party Development Tools
32.0 Packaging Information
- 32.1 Package Marking Information
- 32.2 Package Marking Information
- 32.3 Package Details
Appendix A: Data Sheet Revision History
Product ID System
Trademarks
Worldwide Sales and Service

 2011-2013 Microchip Technology Inc. DS40001609C-page 27

PIC16(L)F1508/9

TABLE 3-9: SPECIAL FUNCTION REGISTER SUMMARY

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Value on

POR, BOR

Value on all

other

Resets

Bank 0

00Ch PORTA — — RA5 RA4 RA3 RA2 RA1 RA0 --xx xxxx --xx xxxx

00Dh PORTB RB7 RB6 RB5 RB4

— — — — xxxx ---- xxxx ----

00Eh PORTC RC7 RC6 RC5 RC4 RC3 RC2 RC1 RC0 xxxx xxxx xxxx xxxx

00Fh

— Unimplemented — —

010h

— Unimplemented — —

011h PIR1 TMR1GIF ADIF RCIF TXIF SSP1IF

— TMR2IF TMR1IF 0000 0-00 0000 0-00

012h PIR2 OSFIF C2IF C1IF

— BCL1IF NCO1IF — — 000- -0-- 000- -0--

013h PIR3

— — — — CLC4IF CLC3IF CLC2IF CLC1IF ---- 0000 ---- 0000

014h

— Unimplemented — —

015h TMR0 Holding Register for the 8-bit Timer0 Count xxxx xxxx uuuu uuuu

016h TMR1L Holding Register for the Least Significant Byte of the 16-bit TMR1 Count xxxx xxxx uuuu uuuu

017h TMR1H Holding Register for the Most Significant Byte of the 16-bit TMR1 Count xxxx xxxx uuuu uuuu

018h T1CON TMR1CS<1:0> T1CKPS<1:0> T1OSCEN T1SYNC

—TMR1ON0000 00-0 uuuu uu-u

019h T1GCON TMR1GE T1GPOL T1GTM T1GSPM T1GGO/

DONE

T1GVAL T1GSS<1:0> 0000 0x00 uuuu uxuu

01Ah TMR2 Timer2 Module Register 0000 0000 0000 0000

01Bh PR2 Timer2 Period Register 1111 1111 1111 1111

01Ch T2CON

— T2OUTPS<3:0> TMR2ON T2CKPS<1:0> -000 0000 -000 0000

01Dh

— Unimplemented — —

01Eh

— Unimplemented — —

01Fh

— Unimplemented — —

Bank 1

08Ch TRISA — — TRISA5 TRISA4 —

(2)

TRISA2 TRISA1 TRISA0 --11 1111 --11 1111

08Dh TRISB TRISB7 TRISB6 TRISB5 TRISB4

— — — — 1111 ---- 1111 ----

08Eh TRISC TRISC7 TRISC6 TRISC5 TRISC4 TRISC3 TRISC2 TRISC1 TRISC0 1111 1111 1111 1111

08Fh

— Unimplemented — —

090h

— Unimplemented — —

091h PIE1 TMR1GIE ADIE RCIE TXIE SSP1IE

— TMR2IE TMR1IE 0000 0-00 0000 0-00

092h PIE2 OSFIE C2IE C1IE

— BCL1IE NCO1IE — — 000- 00-- 000- 00--

093h PIE3

— — — — CLC4IE CLC3IE CLC2IE CLC1IE ---- 0000 ---- 0000

094h

— Unimplemented — —

095h

OPTION_REG

WPUEN INTEDG TMR0CS TMR0SE PSA PS<2:0> 1111 1111 1111 1111

096h PCON STKOVF STKUNF

—RWDTRMCLR RI POR BOR 00-1 11qq qq-q qquu

097h WDTCON

— — WDTPS<4:0> SWDTEN --01 0110 --01 0110

098h

— Unimplemented — —

099h OSCCON

— IRCF<3:0> —SCS<1:0>-011 1-00 -011 1-00

09Ah OSCSTAT SOSCR

—OSTSHFIOFR— — LFIOFR HFIOFS 0-q0 --00 q-qq --qq

09Bh ADRESL ADC Result Register Low xxxx xxxx uuuu uuuu

09Ch ADRESH ADC Result Register High xxxx xxxx uuuu uuuu

09Dh ADCON0

— CHS<4:0>

GO/DONE

ADON -000 0000 -000 0000

09Eh ADCON1 ADFM ADCS<2:0>

— —

ADPREF<1:0>

0000 --00 0000 --00

09Fh ADCON2 TRIGSEL<3:0>

— — — — 0000 ---- 0000 ----

Legend: x = unknown, u = unchanged, q = value depends on condition, - = unimplemented, r = reserved. Shaded locations are unimplemented, read as ‘0’.

Note 1: PIC16F1508/9 only.

2: Unimplemented, read as ‘1’.
