MRF24J40MA
DS00000A-page 18 Advance Information © 2008 Microchip Technology Inc.
TABLE 4: TRANSMITTER AC CHARACTERISTICS
Typical values are at TA = 25°C, VDD = 3.3V, LO Frequency = 2.445 GHz
Parameters Condition Min Typ Max Units
RF Carrier Frequency 2.405 — 2.480 GHz
Maximum RF Output
Power
—0+3dBm
RF Output Power
Control Range
—40—dB
TX Gain Control
Resolution
Programmed by register — 1.25 — dB
Carrier Suppression — -30 — dBc
TX Spectrum Mask for
O-QPSK Signal
Offset frequency > 3.5 MHz,
at 0 dBm output power
-33 — — dBm
