MCP6XXX Amplifier Evaluation Board 4 User’s Guide

TABLE B-2: BILL OF MATERIALS – UNPOPULATED PARTS (102-00154R1)

The BOM in Table B-3 corresponds to the collection of resistors, capacitorys, jumpers

and MCP6021 op amps that come in the Accessory Bag which is shipped in the

MCP6XXX Amplifier Evaluation Board 4 Kit. These components are placed in an

separate ESD bag. They support the circuit in Section 2.4.1 “Building the Amplifier”.

Customers need to provide the resistors and capacitors for more amplifier circuits.

TABLE B-3: BILL OF MATERIALS – ACCESSORY BAG PARTS (102-00148R1)

Qty

Reference Description Manufacturer Part Number

1 U1 MCP6021 PDIP-8, Single Op

Amp

Microchip

Technology Inc

MCP6021-E/P

7 R1-R3, C1, RISO,

RL, CL

Not Populated when shipped to

customer

——

Note 1: The components listed in this Bill of Materials are representative of the PCB assembly. The released BOM

used in manufacturing uses all RoHS-compliant components.

Qty Reference Description Manufacturer Part Number

1 Accessory Bag CAP CER 56PF 50V C0G

RADIAL

Murata Electronics

RPE5C1H560J2P1Z03B

1 Accessory Bag CAP CER 1UF 25V X7R RAD TDK

Corporation FK24X7R1E105K

1 Accessory Bag JUMPER ZERO OHM 1/8W Yageo

Corporation ZOR-12-B-52

2 Accessory Bag RES 8.06K OHM 1/4W 1%

METAL FILM

Yageo Corporation MFR-25FBF-8K06

1 Accessory Bag RES 1.58K OHM 1/4W 1%

METAL FILM

Yageo Corporation MFR-25FBF-1K58

Note 1: The components listed in this Bill of Materials are representative of the PCB assembly. The released BOM

used in manufacturing uses all RoHS-compliant components.
