Appendix B. Bill of Materials (BOM)
B.1 MCP6XXX AMPLIFIER EVALUATION BOARD 4 BOM
The Bill of Materials (BOM) in Table B-1 corresponds to Figure 2-1 and Figure 2-2.
Unpopulated parts are in Table B-2.
TABLE B-1: BILL OF MATERIALS (102-00154R1) (NOTE 1)
Qty Reference Description Manufacturer Part Number
1 CP1 CAP CERAMIC 1UF 10% 25V X5R
0805
Panasonic
®
- ECG ECJ-2FB1E105K
5 CC1, CC2,
C3, CU1, CU2
CAP CERAMIC .1UF 10% 25V X7R
0805
Panasonic - ECG ECJ-2VB1E104K
1 DP1 DIODE ZENER 6.2V 350MW SOT-23 Fairchild
Semiconductor
®
BZX84C6V2
4 EA Corner BUMPER CLEAR .375 x .15" DOME Richco Plastic Co RBS-12
2 JP1, JP3 CONN HEADR BRKWAY .100 04POS
STR
Tyco
®
Electronics/Amp 9-146258-0-02
1 JP2 CONN HEADR BRKWAY .100 06POS
STR
Tyco Electronics/Amp 4-103327-0-06
1 M1 MOSFET N-CH 30V 500MA SOT-346 Rohm RJK005N03T146
1 PCB RoHS Compliant Bare PCB,
MCP6XXX Amplifier Eval Board #4
— 104-00154
14 Pin Socket PIN RECPT .015/.025 DIA 0667 SER Mill-Max
®
0667-0-15-01-30-27-10-0
3 RC1, RC2,
RV1
RES 10.0K OHM 1/8W 1% 0805 SMD Panasonic - ECG ERJ-6ENF1002V
1 RC3 RES 30.1K OHM 1/8W 1% 0805 SMD Panasonic - ECG ERJ-6ENF3012V
1 RC4 RES 49.9K OHM 1/8W 1% 0805 SMD Panasonic - ECG ERJ-6ENF4992V
1 RV2 RES 8.06K OHM 1/8W 1% 0805 SMD Panasonic - ECG ERJ-6ENF8061V
1 RV3 RES 2.0K OHM 1/8W 1% 0805 SMD Panasonic - ECG ERJ-6ENF2001V
2 R4,R5 RES 100 OHM 1/8W 1% 0805 SMD Panasonic - ECG ERJ-6ENF1000V
3 Shunt for JP1,
JP2, JP3
SOCKET,SHORT BLKS W TAB BLK Jameco Value-Pro 2012JH-R
9 Test Points PC TEST POINT COMPACT SMT Keystone Electronics
®
5016
1 UC1 MCP6541 SOT-23-5 Single Op Amp Microchip Technology
Inc.
MCP6541T-I/OT
1 For U1 CONN IC SOCKET 8POS DIP TIN Tyco Electronics/Amp 2-641260-1
Note 1: The components listed in this Bill of Materials are representative of the PCB assembly. The released BOM
used in manufacturing uses all RoHS-compliant components.
