2012-2013 Microchip Technology Inc. DS20002321C-page 47
MCP6491/2/4
PRODUCT IDENTIFICATION SYSTEM
To order or obtain information, e.g., on pricing or delivery, refer to the factory or the listed sales office.
Device: MCP6491T: Single Op Amp (Tape and Reel)
(SC70, SOT-23)
MCP6492: Dual Op Amp (SOIC and MSOP only)
MCP6492T: Dual Op Amp (Tape and Reel)
(SOIC, MSOP and 2x3 TDFN)
MCP6494: Quad Op Amp
MCP6494T: Quad Op Amp (Tape and Reel)
(SOIC and TSSOP)
Temperature Range: E = -40°C to +125°C (Extended)
Package: LTY = Plastic Package (SC70), 5-lead
OT = Plastic Small Outline Transistor, (SOT-23),
5-lead
MNY* = Plastic Dual Flat, No Lead, (2x3 TDFN),
8-lead (TDFN)
SN = Lead Plastic Small Outline (150 mil body),
8-lead (SOIC)
MS = Plastic MSOP, 8-lead
SL = Plastic Small Outline, (150 mil body),
14-lead (SOIC)
ST = Plastic Thin Shrink Small Outline
(150 mil body), 14-lead (TSSOP)
* Y = Nickel palladium gold manufacturing designator. Only
available on the TDFN package.
PART NO. /XX
PackageTemperature
Range
Device
Examples:
a) MCP6491T-E/LTY: Tape and Reel,
Extended Temp.,
5LD SC70 package
b) MCP6491T-E/OT: Tape and Reel,
Extended Temp.,
5LD SOT-23 package
c) MCP6492-E/MS: Extended Temp.,
8LD MSOP package
d) MCP6492T-E/MS: Tape and Reel,
Extended Temp.,
8LD MSOP package
e) MCP6492-E/SN: Extended Temp.,
8LD SOIC package
f) MCP6492T-E/SN: Tape and Reel,
Extended Temp.,
8LD SOIC package
g) MCP6492T-E/MNY: Tape and Reel,
Extended Temp.,
8LD 2x3 TDFN package
h) MCP6494-E/SL: Extended Temp., 14LD
SOIC package
i) MCP6494T-E/SL: Tape and Reel,
Extended Temp., 14LD
SOIC package
j) MCP6494-E/ST: Extended Temp.,
14LD TSSOP package
k) MCP6494T-E/ST: Tape and Reel,
Extended Temp.,
14LD TSSOP package
-X
