MCP6031 PHOTODIODE PICtail™
PLUS DEMO BOARD USER’S GUIDE
© 2008 Microchip Technology Inc. DS51763A-page 5
Chapter 1. Product Overview
1.1 INTRODUCTION
The MCP6031 Photodiode PICtail™ Plus Demo Board is described by the following:
• Assembly # : 114-00219
• Order # : MCP6031DM-PCTL
• Name: MCP6031 Photodiode PICtail™ Plus Demo Board
Items discussed in this chapter include:
• MCP6031 Photodiode PICtail™ Plus Demo Board Kit Contents
• MCP6031 Photodiode PICtail™ Plus Demo Board Description
1.2 MCP6031 PHOTODIODE PICtail™ PLUS DEMO BOARD KIT CONTENTS
• MCP6031 Photodiode PICtail™ Plus Demo Board (102-00219)
• Important Information “Read First”
• Analog and Interface Products Demonstration Boards CD-ROM (DS21912). It
contains:
- MCP6031 Photodiode PICtail™ Plus Demo Board User’s Guide (DS51763)
- Firmware files
- Gerber files
FIGURE 1-1: MCP6031 Photodiode PICtail™ Plus Demo Board Kit.
