User manual

MCP6031 PHOTODIODE PICtail™
PLUS DEMO BOARD USER’S GUIDE
© 2008 Microchip Technology Inc. DS51763A-page 15
Appendix B. Bill of Materials (BOM)
TABLE B-1: BILL OF MATERIALS (102-00219)
TABLE B-2: BILL OF MATERIALS - UNPOPULATED PARTS
Qty Reference Description Manufacturer Part Number
1 C2 CAP 33,000PF 50V CERM X7R
0805
Panasonic
®
ECJ-2VB1H333K
2 C3, C4 CAP .1UF 25V CERAMIC X7R
0805
Panasonic
®
ECJ-2VB1E104K
1 C5 CAP 1.0UF 16V CERAMIC X7R
0805
Kemet
®
Electronics Corp. C0805C105K4RACTU
1 D1 PIN PHOTODIODE Panasonic
®
PNZ334
1 R1 RES 42.2K OHM 1/10W 1% 0805
SMD
Panasonic
®
ERJ-6ENF4222V
1 R2 RES 10.0K OHM 1/10W 1% 0805
SMD
Panasonic
®
ERJ-6ENF1002V
3 TP1—TP3 TEST POINT PC COMPACT SMT Keystone Electronics 5016
1 U1 MCP6031, SOT-23-5 Microchip Technology Inc. MCP6031T-E/OT
Note: The components listed in this Bill of Materials are representative of the PCB assembly. The
released BOM used in manufacturing uses all RoHS-compliant components.
Qty Reference Description Manufacturer Part Number
1 C1 Not Populated when shipped to
customer
——
Note: The components listed in this Bill of Materials are representative of the PCB assembly. The
released BOM used in manufacturing uses all RoHS-compliant components.
